trigger-only—NQA displays results on the terminal screen, and meanwhile triggers other
modules for collaboration.
The DNS operation does not support the action of sending trap messages.
Reaction entry
In a reaction entry, configure a monitored element, a threshold type, and an action to be triggered to
implement threshold monitoring.
The state of a reaction entry can be invalid, over-threshold, or below-threshold.
•
Before an NQA operation starts, the reaction entry is in invalid state.
•
If the threshold is violated, the state of the entry is set to over-threshold. Otherwise, the state of
the entry is set to below-threshold.
If the action is trap-only for a reaction entry, a trap message is sent to the NMS when the state of the
entry changes.
Configuration procedure
Before you configure threshold monitoring, configure the destination address of the trap messages
by using the snmp-agent target-host command. For more information about the command, see
Network Management and Monitoring Command Reference.
To configure threshold monitoring:
Step
1. Enter system view.
2. Create an NQA
operation
enter
operation view.
3. Enter
operation view.
4. Enable
traps to the NMS
when
conditions
met.
5. Configure
threshold
monitoring.
Command
system-view
and
nqa entry admin-name operation-tag
NQA
type { dhcp | dlsw | dns | ftp | http |
NQA
icmp-echo | icmp-jitter | snmp | tcp |
udp-echo | udp-jitter | udp-tracert | voice }
sending
reaction trap { path-change | probe-failure
specific
consecutive-probe-failures | test-complete |
are
test-failure [ accumulate-probe-failures ] }
•
Monitor the operation duration (not
supported in the ICMP jitter, UDP jitter,
UDP tracert,
reaction
checked-element
threshold-type
accumulate-occurrences | average |
consecutive consecutive-occurrences }
threshold-value
lower-threshold [ action-type { none |
trap-only } ]
or voice operations):
item-number
probe-duration
{ accumulate
upper-threshold
111
Remarks
N/A
By default, no NQA operations
exist.
The threshold monitoring feature
is not available for the path jitter
operation.
By default, no traps are sent to
the NMS.
The ICMP jitter, UDP jitter, and
voice operations support only
the test-complete keyword.
The following parameters are not
available for the UDP tracert
operation:
•
The probe-failure
consecutive-probe-failures
option.
•
The
accumulate-probe-failures
argument.
N/A
