- Page 1 HPE FlexNetwork 5130 HI Switch Series Installation Guide Part number: 5998-8420h Document version: 6W104-20201020...
- Page 2 © Copyright 2016, 2020 Hewlett Packard Enterprise Development LP The information contained herein is subject to change without notice. The only warranties for Hewlett Packard Enterprise products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. Hewlett Packard Enterprise shall not be liable for technical or editorial errors or omissions contained herein.
-
Page 3: Table Of Contents
Mounting bracket kits ································································································································· 8 Rack-mounting by using front mounting brackets ······················································································ 8 Rack-mounting by using front and rear mounting brackets (HPE 5130 24G PoE+ 4SFP+ 1-slot HI and HPE 5130 48G PoE+ 4SFP+ 1-slot HI) ············································································································ 12 Mounting the switch on a workbench ··············································································································· 15 Grounding the switch ·······································································································································... - Page 4 Garbled display ········································································································································ 42 Appendix A Chassis views and technical specifications ······························· 44 Chassis views ·················································································································································· 44 HPE 5130 24G 4SFP+ 1-slot HI ·············································································································· 44 HPE 5130 24G PoE+ 4SFP+ 1-slot HI····································································································· 45 HPE 5130 48G 4SFP+ 1-slot HI ·············································································································· 46 HPE 5130 48G PoE+ 4SFP+ 1-slot HI·····································································································...
-
Page 5: Preparing For Installation
HPE 5130/5510 10GbE SFP+ 2-port Module LSWM2SP2PM For regulatory identification purposes, the HPE 5130 HI switches are assigned regulatory model numbers (RMNs), which are listed in the following table. These regulatory numbers should not be confused with the marketing name HPE 5130 HI, or the product codes. -
Page 6: Examining The Installation Site
• Do not place the switch on an unstable case or desk. The switch might be severely damaged in case of a fall. • Ensure good ventilation of the equipment room and keep the air inlet and outlet vents of the switch free of obstruction. -
Page 7: Emi
Table 2 Dust concentration limit in the equipment room Substance Concentration limit (particles/m ≤ 3 x 10 Dust (no visible dust on the tabletop over three days) NOTE: Dust diameter ≥ 5 μm The equipment room must also meet limits on salts, acids, and sulfides to eliminate corrosion and premature aging of components, as shown in Table Table 3 Harmful gas limits in the equipment room... -
Page 8: Installation Accessories
1 kit All HPE 5130 HI switches Rear mounting bracket kit (including one pair of mounting brackets and two load-bearing • HPE 5130 24G PoE+ 4SFP+ 1-slot HI screws) 5190-0297 1 kit • HPE 5130 48G PoE+ 4SFP+ 1-slot HI... - Page 9 Product Description Quantity Applicable models code Power supply filler panel • HPE 5130 24G PoE+ 4SFP+ 1-slot HI 5190-1774 • HPE 5130 48G PoE+ 4SFP+ 1-slot HI Interface card filler panel 5190-0296 All HPE 5130 HI switches HPE X722 port to power fan...
-
Page 10: Installing The Switch
CAUTION: Keep the tamper-proof seal on a mounting screw on the chassis cover intact, and if you want to open the chassis, contact HPE for permission. Otherwise, HPE shall not be liable for any consequence. Figure 1 Hardware installation flow... -
Page 11: Installing The Switch In A 19-Inch Rack
Installing the switch in a 19-inch rack Installation methods Table 5 Installation methods for the HPE 5130 HI switches Installation Installation Chassis Installation requirements methods procedure • HPE 5130 24G Using front The mounting bracket kit can be "Rack-mounting by... -
Page 12: Mounting Bracket Kits
Mounting bracket kits Table 6 Mounting bracket kits for the HPE 5130 HI switches HPE 5130 24G 4SFP+ 1-slot HI HPE 5130 24G PoE+ 4SFP+ 1-slot HI Mounting bracket kits HPE 5130 48G 4SFP+ 1-slot HI HPE 5130 48G PoE+ 4SFP+ 1-slot HI... - Page 13 You can install the front mounting brackets at one of the following positions: HPE 5130 24G 4SFP+ 1-slot HI and HPE 5130 48G 4SFP+ 1-slot HI switches—Port side, power supply side, or mid-mounting position. HPE 5130 24G PoE+ 4SFP+ 1-slot HI and HPE 5130 48G PoE+ 4SFP+ 1-slot HI ...
- Page 14 Figure 8 Attaching the front mounting bracket to the mid-mounting position Mount the chassis in the rack: a. One person supports the chassis bottom with one hand, holds the front part of the chassis with the other hand, and pushes the chassis into the rack gently b.
- Page 15 Figure 10 Mounting the switch in the rack (front mounting brackets at the power supply side) Figure 11 Mounting the switch in the rack (front mounting brackets at the mid-mounting position)
-
Page 16: Rack-Mounting By Using Front And Rear Mounting Brackets
(HPE 5130 24G PoE+ 4SFP+ 1-slot HI and HPE 5130 48G PoE+ 4SFP+ 1-slot HI) This mounting method is applicable only to the HPE 5130 24G PoE+ 4SFP+ 1-slot HI and HPE 5130 48G PoE+ 4SFP+ 1-slot HI switches. You can install the front mounting brackets at the port-side or power-side mounting position as needed. - Page 17 Figure 13 Attaching the rear mounting brackets to the rack with the wide flange inside the rack Figure 14 Attaching the rear mounting brackets to the rack with the wide flange outside the rack Mount the switch chassis in the rack: a.
- Page 18 b. The other person aligns the oval holes in the front brackets with the mounting holes in the front rack posts, and attaches the front mounting brackets with M6 screws (user supplied) to the front rack posts. Tighten the screws and make sure the front and rear mounting brackets have securely attached the switch to the rack.
-
Page 19: Mounting The Switch On A Workbench
Mounting the switch on a workbench IMPORTANT: • Ensure good ventilation and 10 cm (3.9 in) of clearance around the chassis for heat dissipation. • Avoid placing heavy objects on the switch. To mount the switch on a workbench: Verify that the workbench is sturdy and reliably grounded. Place the switch with bottom up, and clean the round holes in the chassis bottom with dry cloth. - Page 20 (4) Grounding hole (5) Grounding cable Connecting the grounding cable to a grounding strip (for the HPE 5130 24G PoE+ 4SFP+ 1-slot HI and HPE 5130 48G PoE+ 4SFP+ 1-slot HI switches) Remove the hex nut of a grounding post on the grounding strip.
-
Page 21: Grounding The Switch With A Grounding Conductor Buried In The Earth Ground
(3) Grounding cable (4) Hex nut Connecting the grounding cable to a grounding strip (for the HPE 5130 24G 4SFP+ 1-slot HI and HPE 5130 48G 4SFP+ 1-slot HI switches) Remove the hex nut of a grounding post on the grounding strip. -
Page 22: Installing/Removing A Power Supply
Figure 21 Grounding the switch by burying the grounding conductor into the earth ground (1) Grounding screw (2) Chassis rear panel (3) Grounding cable (4) Earth (5) Joint (6) Grounding conductor Installing/removing a power supply WARNING! In power redundancy mode, you can replace a power supply without powering off the switch but you must strictly follow the installation and removal procedures in Figure 22 Figure 23... - Page 23 For the PSR150-A/PSR150-A1 (JD362A/JD362B) and PSR150-D/PSR150-D1 (JD366A/JD366B) power supplies, the installation and removal procedures are the same. The following takes the PSR150-A1 (JD362B) power supply as an example. To install a power supply: Wear an ESD wrist strap and make sure it makes good skin contact and is reliably grounded. Remove the filler panel from the target power supply slot as follows: a.
-
Page 24: Removing A Psr150(Jd362A, Jd362B, Jd366A, Or Jd366B) Power Supply
Removing a PSR150(JD362A, JD362B, JD366A, or JD366B) power supply Wear an ESD wrist strap and make sure it makes good skin contact and is reliably grounded. Disconnect the power cord. Loosen the captive screws of the power supply with a Phillips screwdriver until they are completely disengaged. -
Page 25: Removing A Psr720-56A/Psr1110-56A (Jg544A/Jg545A) Power Supply
Correctly orient the power supply with the power supply slot (use the letters on the power supply faceplate for orientation), grasp the handle of the power supply with one hand and support its bottom with the other, and slide the power supply slowly along the guide rails into the slot until you hear that the latch of the power supply clicks into the slot. -
Page 26: Connecting The Power Cord
Figure 28 Removing the power supply Connecting the power cord CAUTION: • The PSR150-A/PSR150-A1 (JD362A/JD362B) power supplies are provided with an AC power cord that uses a C13 connector. The PSR720-56A/PSR1110-56A (JG544A/JG545A) power supplies are provided with an AC power cord that uses a high-temperature C15 connector. Do not confuse the power cords. -
Page 27: Connecting A Psr150-D/Psr150-D1 (Jd366A/Jd366B) Power Supply
Connecting a PSR150-D/PSR150-D1 (JD366A/JD366B) power supply WARNING! • HPE DC power cords are required if the –48 VDC power source is used. RPS power cords are required if the RPS power source is used. • The power cord color code scheme in Figure 29 is for illustration only. -
Page 28: Installing/Removing An Interface Card
Use a cable tie to secure the power cord to the handle of the power supply (see callout 2 and callout 3 in Figure 30). Connect the other end of the AC power cord to an AC power outlet. Figure 30 Connecting a PSR720-56A (JG544A) power supply Installing/removing an interface card CAUTION: •... - Page 29 Figure 31 Removing the filler panel over an interface card slot Unpack the interface card. Perform the following steps to install the interface card: a. Rotate rightward the ejector lever on the interface card. b. Gently push the interface card into the slot along the guide rails until the interface card has good contact with the chassis.
-
Page 30: Removing An Interface Card
Figure 32 Installing an interface card Removing an interface card Wear an ESD wrist strap and make sure it makes good skin contact and is reliably grounded. Use a Phillips screwdriver to completely loosen the captive screw on the interface card. Rotate rightward the ejector lever on the interface card. - Page 31 • All the interface cables are cabled indoors. If any cable is routed outdoors, verify that the socket strip with lightning protection and lightning arresters for network ports have been correctly connected.
-
Page 32: Accessing The Switch For The First Time
Accessing the switch for the first time Setting up the configuration environment You can access the switch through the serial console port or the mini USB console port. The switch is not provided with a serial console cable or Mini USB console cable. Prepare these cables yourself or purchase them from Hewlett Packard Enterprise. -
Page 33: Connecting The Mini Usb Console Cable
RJ-45 Signal DB-9 Signal To connect a configuration terminal (for example, a PC) to the switch: Plug the DB-9 female connector of the console cable to the serial port of the PC. Connect the RJ-45 connector to the console port of the switch. NOTE: •... - Page 34 Figure 35 Device Driver Installation Wizard Click Continue Anyway if the following dialog box appears. Figure 36 Software Installation Click Finish.
-
Page 35: Setting Terminal Parameters
Figure 37 Completing the device driver installation wizard Setting terminal parameters To configure and manage the switch through the console port, you must run a terminal emulator program, TeraTermPro or PuTTY, on your PC. You can use the emulator program to connect a network device, a Telnet site, or an SSH site. - Page 36 After the startup completes, you can access the CLI to configure the switch. For more information about the configuration commands and CLI, see HPE 5130 HI Switch Series Configuration Guides and HPE 5130 HI Switch Series Command References.
-
Page 37: Setting Up An Irf Fabric
Setting up an IRF fabric You can use HPE IRF technology to connect and virtualize HPE 5130 HI switches into a large virtual switch called an "IRF fabric" for flattened network topology, and high availability, scalability, and manageability. IRF fabric setup flowchart... -
Page 38: Planning Irf Fabric Setup
Distribute the IRF member switches in different racks to implement the ToR access solution for a data center. NOTE: For the maximum number of IRF member devices in an HPE 5130 HI IRF fabric, see the release notes. Identifying the master switch and planning IRF member IDs Determine which switch you want to use as the master for managing all member switches in the IRF fabric. -
Page 39: Identifying Physical Irf Ports On The Member Switches
As a best practice to avoid loop topology, first complete IRF configuration and then connect the IRF member switches. The HPE 5130 HI switches can provide 10-GE IRF connections through SFP+ ports, and you can bind several SFP+ ports to an IRF port for increased bandwidth and availability. -
Page 40: Planning The Cabling Scheme
SFP+ cables and SFP+ transceiver modules, see "Appendix C Ports and LEDs." The following subsections describe several HPE recommended IRF connection schemes, and all these schemes use a ring topology. IMPORTANT: In these schemes, all physical IRF ports are located on the same side. If physical IRF ports are on different sides, you must measure the distance between them to select an appropriate cable. - Page 41 Figure 41 Connecting the switches in one rack...
-
Page 42: Configuring Basic Irf Settings
• Execute the display irf configuration command to verify the basic IRF settings. For more information about configuring basic IRF settings, see HPE 5130 HI Switch Series IRF Configuration Guide. Connecting the physical IRF ports As a best practice to avoid loop topology, first complete IRF configuration and then connect the IRF member switches. -
Page 43: Verifying The Irf Fabric Setup
To avoid IP address collision and network problems, configure a minimum of one multi-active detection (MAD) mechanism to detect the presence of multiple identical IRF fabrics and handle collisions. For more information about MAD detection, see HPE 5130 HI Switch Series IRF Configuration Guide. -
Page 44: Maintenance And Troubleshooting
Symptom The power supply status LEDs are not steady green. For the HPE 5130 24G 4SFP+ 1-slot HI and HPE 5130 48G 4SFP+ 1-slot HI switches, examine the PWR1 or PWR2 LED of the switch to identify power supply failure. -
Page 45: Removing A Fan Tray
Removing a fan tray WARNING! • Do not touch any bare conductors or terminals on the fan tray. • Do not place the fan tray in a moist place. Prevent liquid from entering the fan tray. • Do not disassemble faulty fan trays yourself. When the internal wiring or components of a fan tray are faulty, ask maintenance engineers for maintenance. -
Page 46: Configuration Terminal Display Problems
Verify that the power supply is supplying power to the switch. Verify that the console cable is correctly connected. Verify that the console cable does not have any problems and the PC settings are correct. If the problem persists, contact HPE Support. Garbled display Symptom The display on the PC is garbled. - Page 47 Data bits—8. Parity—None. Stop bits—1. Flow control—None. If the problem persists, contact HPE Support.
-
Page 48: Appendix A Chassis Views And Technical Specifications
(6) Power supply 2 (optional) The HPE 5130 24G 4SFP+ 1-slot HI switch comes with power supply slot 1 empty and power supply slot 2 installed with a filler panel. You can install one or two power supplies for the switch as required. -
Page 49: Hpe 5130 24G Poe+ 4Sfp+ 1-Slot Hi
The HPE 5130 24G 4SFP+ 1-slot HI switch comes with a filler panel in the interface card slot. You can select an interface card for the switch as required. In this figure, an LSWM2SP2PM interface card is installed in the interface card slot. For more information about installing and removing an interface card, see "Installing/removing an interface... -
Page 50: Hpe 5130 48G 4Sfp+ 1-Slot Hi
"Installing/removing a power supply." The HPE 5130 48G 4SFP+ 1-slot HI switch comes with a filler panel in the interface card slot. You can select an interface card for the switch as required. In this figure, an LSWM2SP2PM interface card is installed in the interface card slot. For more information about installing and removing an interface card, see "Installing/removing an interface... -
Page 51: Hpe 5130 48G Poe+ 4Sfp+ 1-Slot Hi
"Installing/removing a power supply." The HPE 5130 48G PoE+ 4SFP+ 1-slot HI switch comes with a filler panel in the interface card slot. You can select an interface card for the switch as required. In this figure, an LSWM2SP2PM interface card is installed in the interface card slot. -
Page 52: Technical Specifications
Technical specifications Table 11 Technical specifications for non-PoE switch models Item HPE 5130 24G 4SFP+ 1-slot HI HPE 5130 48G 4SFP+ 1-slot HI 43.6 × 440 × 360 mm 43.6 × 440 × 360 mm Dimensions (H × W ×... - Page 53 Table 12 Technical specifications for PoE switch models HPE 5130 24G PoE+ 4SFP+ Item HPE 5130 48G PoE+ 4SFP+ 1-slot HI 1-slot HI 43.6 × 440 × 460 mm 43.6 × 440 × 460 mm Dimensions (H × W ×...
- Page 54 Fire resistance UL60950-1, EN60950-1, IEC60950-1, GB4943 compliance The following table describes PoE power capacity for the HPE 5130 24G PoE+ 4SFP+ 1-slot HI and HPE 5130 48G PoE+ 4SFP+ 1-slot HI switches: HPE 5130 24G PoE+ 4SFP+ HPE 5130 48G PoE+ 4SFP+ 1-slot HI...
-
Page 55: Appendix B Frus And Compatibility Matrixes
You can install one power supply, or two power supplies for redundancy on the HPE 5130 24G 4SFP+ 1-slot HI and HPE 5130 48G 4SFP+ 1-slot HI switches. These switches support mix of an AC power supply and a DC power supply. -
Page 56: Hot Swappable Interface Cards
Power supply Specifications Reference • Rated input voltage range: –48 VDC to –60 VDC HPE PSR150-A & PSR150-D PSR150-D/PSR150-D1 • Max input voltage range: –36 VDC to Power Supplies User Guide (JD366A/JD366B) –72 VDC • Max output power: 150 W •... - Page 57 • For ports adjacent to one another on the device, the peer ports on the distribution frame is preferably not adjacent, for example: If the device connects to one distribution frame, connect port 1 on the device to port 1 on the ...
-
Page 58: Appendix C Ports And Leds
NOTE: USB devices from different vendors vary in compatibilities and drivers. HPE does not guarantee the correct operation of USB devices from all vendors on the switch. If a USB device fails to operate on... -
Page 59: 10/100/1000Base-T Autosensing Ethernet Port
(nm) (µm) (MHz × km) distance 550 m (1804.46 ft) Multi-mode, HPE X120 50/125 500 m (1640.42 ft) 1G SFP LC JD118B 275 m (902.23 ft) Multi-mode, Transceiver 62.5/125 220 m (721.78 ft) Single-mode, 10 km (6.21 miles) - Page 60 Modal Product Conn wavelength diameter bandwidth transmission code description ector (nm) (µm) (MHz × km) distance HPE X125 1G SFP LC Single-mode, 70 km (43.50 JD063B 1550 LH70 9/125 miles) Transceiver HPE X120 1G SFP LC Single-mode, 100 km (62.14...
- Page 61 Table 18 SFP+ DAC cables available for the SFP+ ports Product code HPE description Max transmission distance JD095B HPE X240 10G SFP+ SFP+ 0.65m DA Cable 0.65 m (2.13 ft) JD096B HPE X240 10G SFP+ SFP+ 1.2m DA Cable 1.2 m (3.94 ft)
-
Page 62: Leds
Figure 55 SFP+ active optical cable NOTE: • The fixed SFP+ ports on the switch do not support the HPE X130 10G SFP+ LC LRM Transceiver, HPE X130 10G SFP+ LC LH 80km Transceiver, and HPE X130 10G SFP+ LC ER 40km Transceiver. -
Page 63: Led For The Port Led Mode (Mode)
The port status LEDs are showing port rates. Flashing green (1 Hz) (available only for HPE 5130 24G PoE+ 4SFP+ The port status LEDs are showing the status of 1-slot HI and HPE 5130 48G PoE+ PoE power supply on the ports. 4SFP+ 1-slot HI switches) MODE The port status LEDs indicates the IRF member ID of the switch. -
Page 64: Sfp+ Port Led
Flashing green (1 Hz) (PoE mode, Flashing green (3 Hz) currently available PoE output power on available only for HPE 5130 24G the port. PoE+ 4SFP+ 1-slot HI and HPE 5130 48G PoE+ 4SFP+ 1-slot HI Steady yellow The port is experiencing a PoE failure. -
Page 65: Interface Card Status Led
Interface card status LED The switch provides an interface card slot at the rear. The interface card status LED on the front panel indicates the operating state of the interface card. Table 26 Interface card status LED description LED mark Status Description Steady green... -
Page 66: Appendix D Cooling System
Figure Figure 56 Airflow through the HPE 5130 48G 4SFP+ 1-slot HI switch IMPORTANT: The chassis and the power supplies use separate air aisles. Make sure both aisles are not blocked. -
Page 67: Document Conventions And Icons
Document conventions and icons Conventions This section describes the conventions used in the documentation. Port numbering in examples The port numbers in this document are for illustration only and might be unavailable on your device. Command conventions Convention Description Boldface Bold text represents commands and keywords that you enter literally as shown. -
Page 68: Network Topology Icons
Convention Description An alert that provides helpful information. TIP: Network topology icons Convention Description Represents a generic network device, such as a router, switch, or firewall. Represents a routing-capable device, such as a router or Layer 3 switch. Represents a generic switch, such as a Layer 2 or Layer 3 switch, or a router that supports Layer 2 forwarding and other Layer 2 features. -
Page 69: Support And Other Resources
Support and other resources Accessing Hewlett Packard Enterprise Support • For live assistance, go to the Contact Hewlett Packard Enterprise Worldwide website: www.hpe.com/assistance • To access documentation and support services, go to the Hewlett Packard Enterprise Support Center website: www.hpe.com/support/hpesc Information to collect •... -
Page 70: Websites
Websites Website Link Networking websites Hewlett Packard Enterprise Information Library for www.hpe.com/networking/resourcefinder Networking Hewlett Packard Enterprise Networking website www.hpe.com/info/networking Hewlett Packard Enterprise My Networking website www.hpe.com/networking/support Hewlett Packard Enterprise My Networking Portal www.hpe.com/networking/mynetworking Hewlett Packard Enterprise Networking Warranty www.hpe.com/networking/warranty General websites Hewlett Packard Enterprise Information Library www.hpe.com/info/enterprise/docs... -
Page 71: Documentation Feedback
Hewlett Packard Enterprise is committed to providing documentation that meets your needs. To help us improve the documentation, send any errors, suggestions, or comments to Documentation Feedback (docsfeedback@hpe.com). When submitting your feedback, include the document title, part number, edition, and publication date located on the front cover of the document. For online help content, include the product name, product version, help edition, and publication date located on the legal notices page. -
Page 72: Index
Index PSR150-D1, Numerics PSR720-56A/PSR1110-56A/PSR150-A1, 10/100/1000 Base-T autosensing Ethernet USB mini console cable, port, console port LED, connecting cable, 19-inch rack connecting USB mini cable, mounting bracket kit, port technical specifications, switch installation, data bits (parameter), access device first time switch access, troubleshooting fan failure, accessories needed for installation, troubleshooting power supply module,... - Page 73 site dust concentration, management Ethernet port LED, site gas saturation, management Ethernet port technical specifications, site humidity, mounting bracket kit, site temperature, port mode LED, examining installation site, port technical specifications, power supply, power supply input status, failure (troubleshooting), power supply output status, fan tray power supply removal, installation,...
- Page 74 installation, member removal, configuring IRF member switch basic settings, Interface card connecting IRF physical ports, status LED, identifying IRF member switch physical ports, interface card IRF member ID, installation, mounting port status LED, workbench mounting switch, technical specifications, interface card status LED, network management IRF fabric setting up IRF fabric,...
- Page 75 preventing EMI prevention, rack procedure mounting switch to workbench, configuring IRF basic settings, switch installation in 19-inch rack, connecting grounding cable to chassis, switch installation methods, connecting grounding cable to grounding strip, verifying switch installation, 16, 17 removing connecting IRF physical ports, interface card, connecting power cord, power supply,...
- Page 76 grounding with a grounding conductor buried tools needed for installation, in the earth ground, topology grounding with grounding strip, planning IRF cabling scheme, 36, 36 identifying IRF master switch, topology (IRF fabric), identifying IRF member switch physical ports, troubleshooting configuration terminal problems, installation, 1, 6 fan failure,...
