13.7.4 TOD Seconds Alarm Register (TODSAL)
When the value contained in this register matches the value of the seconds counter, the seconds
alarm is asserted if the Seconds Alarm Enable (TODSA) bit and Alarm Interrupt Enable
(TODAEN) bits are set and all other enabled alarm registers also match.
BASE +:$3
15
Read
0
Write
Reset
0
Figure 13-6. TOD Seconds Alarm Register (TODSAL)
13.7.5 TOD Minutes Counter (TODMIN)
When TODEN is set, this counter is continuously updated to contain the current minutes value.
The value of the counter can be read through the corresponding minutes latch, but it cannot be
modified. When TODEN is cleared, TOD counting is disabled and this counter can be modified.
When TODEN is set to one again, the counting resumes from the new set time.
BASE + $4
15
Read
0
Write
Reset
0
12
14
13
12
11
10
0
0
0
0
0
0
0
0
0
0
Figure 13-5. TOD Seconds Register (TODSEC)
See Programmer's Sheet on Appendix page B-101
14
13
12
11
10
0
0
0
0
0
0
0
0
0
0
See Programmer's Sheet on Appendix page B-102
14
13
12
11
10
0
0
0
0
0
0
0
0
0
0
Figure 13-7. TOD Minutes Register (TODMIN)
See Programmer's Sheet on Appendix page B-103
