Application:
ADC ADC
arch.h: ArchIO.Adc.Control2Reg
registers.h: ArchIO_Control2Reg
ADC Control
Register (ADCR2)
ADC_BASE+$1
C
Reserved Bits
52
(826 only)
(827 only)
Bits 15 14 13 12
Read 0 0 0 0
Write
Reset 0 0 0 0
56F826/827 User Manual, Rev. 3
ADC Control Register 2 (ADCR2)
DIV
0–15
11 10 9 8 7 6
0 0 0 0 0 0
0 0 0 0 0 0
Date:
Programmer:
2 of 13
Sheet
Clock Divisor Select
Clock Divisor Select Value =
N = DIV[4:] + 1
F = (F ) / 2N
ADC IPR
F = Analog-to-Digital
ADC
Converter Frequency
F = Interface Peripheral Bus
IPR
Clock Frequency
5 4 3 2 1 0
0
DIV
0 0 1 1 1
