- Page 1 Starter TRAK Quick Start Guide for TRK-MPC5604B TRK-MPC5604B Automotive body and industrial applications...
- Page 2 Figure 1: TRK-MPC5604B Board* TRK-MPC5604B Freescale StarterTRAK The TRK-MPC5604B board is part of the Freescale StarterTRAK series, a development platform that enables rapid prototyping and tool re-use. Take your design to the next level and begin constructing with your StarterTRAK system today.
- Page 3 See pemicro.com/osbdm for • LIN interface source code • Analog interface with potentiometer • High-effieiency LEDs • SCI serial communication interface Step-by-Step Installation Instructions In this Quick Start Guide, you will learn how to set up the TRK-MPC5604B board and run the default low-power lab exercise. STEP Install Software • Install RAppID initialization tool and Tools Install in the order listed. These programs are • Install CodeWarrior Development...
-
Page 4: Connect The Usb Cable
Note: The lab exercise to use low power is located STEP Explore Further with the on p.110 in section 13.3.1. Check freescale.com/ MPC5500 and MPC5600 TRK-MPC5604B for the latest training and labs. Simple Cookbook: Low-Power Lab Exercise To run a demonstration using the TRK-MP5604B, follow the instructions for... - Page 5 Starter TRAK Quick Start Guide for TRK-MPC5604B TRK-MPC5604B Jumper Options The following is a list of all jumper options. Jumper Option Setting Description External Power 9V DC to 12V DC Regulated Down to 5V DC System Power USB OSBDM Supplies 5V DC...
- Page 6 Starter TRAK TRK-MPC5604B Jumper Options (continued from previous page) Jumper Option Setting Description MCU LIN0TX to Transceiver LIN TXD Signal MCU LIN1TX to Transceiver MCU LIN0RX to Transceiver LIN RXD Signal MCU LIN1RX to Transceiver MCU VDD Enable Provides Power to MCU, Current Measurement...
- Page 7 Starter TRAK Quick Start Guide for TRK-MPC5604B TRK-MPC5604B Jumper Options (continued from previous page) Jumper Option Setting Description Push Button Signals 1-2, 3-4, Connects MCU Port A2, A4, G3 and G5 to Corresponding Push Buttons Enable 5-6, 7-8 1-2, 3-4,...
- Page 8 Starter TRAK To learn more, please visit freescale.com/StarterTRAK. Freescale, the Freescale logo and CodeWarrior are trademarks of Freescale Semiconductor, Inc., Reg. U.S. Pat. & Tm. Off. All other product or service names are the property of their respective owners. © 2010 Freescale Semiconductor, Inc. Doc Number: MPC5604BQSG / REV 0 Agile Number: 926-26780 / REV A...
