Application:
SSI
arch.h: ArchIO.Ssi.ReceiveReg
registers.h: ArchIO_Ssi_ReceiveReg
Bits
SSI Receive
Read
Register (SRX)
SSI_BASE+$1 Write
Reset
Reserved Bits
Freescale Semiconductor
SSI Receive Register (SRX)
15 14 13 12 11 10
HIGH BYTE
0 0 0 0 0 0
Appendix B - Programmer's Sheets, Rev. 3
Date:
Programmer:
Receive
Data received to be written to the SSI Receive Data
register (SRX).
The register always accepts data from the Receiver
Shift Register as it becomes full. If FIFO is enabled,
the Receive Data Register then receives its values
from this FIFO register after SSI Receive Data (SRX)
register is full.
9 8 7 6 5 4
LOW BYTE
0 0 0 0 0 0
Sheet
2 of 9
3 2 1 0
0 0 0 0
