Step 4: The DIP switches S1 and S2 on the D4-04AD
correspond to the number of active channels
Number of
Active Channels jumpers on the F4-04AD. The figure on the
right shows that these are a subset of the
Selection
jumper block, and include J7 and J8. Observe
the present switch setting on the D4-04AD.
Then find the row in the table below that
matches,
jumpers to match.
Channel 1
Channels 1 and 2
Channels 1, 2 and 3
Channels 1 ,2 ,3 and 4
Now you have all the necessary information to get your analog module installed and
operating correctly.
Units Select Cross-Reference
Units or Format
and configure
Number of Active Channels Cross-Reference
Channels Enabled
F4–04AD 4 Channel Analog Input
D4-04AD
Switch Setting
SW3=ON
SW3=OFF
the F4-04AD
D4-04AD
Switch Settings
SW1=ON
SW2=ON
SW1=ON
SW2=OFF
SW1=OFF
SW2=ON
SW1=OFF
SW2=OFF
F4-04AD
Jumper Settings
1
0
1
0
J1
J2
J3
J4
J5
J6
Number
J7 1
of Active
J8 0
Channels
F4-04AD
Jumper Settings
1
0
1
0
1
0
1
0
3–35
