D4-02DA 2-Channel Analog Output
Module Operation
DL430 Special
Requirements
V40502
MSB
Y
5
7
Even though the module can be placed in any slot, it is important to examine the
configuration if you're using a DL430 CPU. As you'll see in the section on writing the
program, you use V-memory locations to extract the analog data. As shown in the
following diagram, if you place the module so that the input points do not start on a
V-memory boundary, the instructions can't access the data.
Correct!
Data is correctly entered so input points
start on a V-memory boundary address.
MSB
V40502
Y Y Y
5 5 4
7 0 7
Wrong!
Data is split over three locations, so instructions
cannot access data from a DL430.
