Module Operation

DL430 Special Even though the module can be placed in any slot, it is important to examine the
Requirements configuration if you are using a DL430 CPU. As you can see in the section on writing
the program, you use V-memory locations to extract the analog data. As shown in
the following diagram, if you place the module so that the input points do not start on
a V-memory boundary, the instructions cannot access the data.
Correct!
Wrong!
Data is split over two locations, so instructions cannot access data from a DL430.
V40401
MSB
X X X
3 3 2
7 0 7
F4-04ADS 4-Channel Isolated Analog Input
F4–04ADS
8pt 8pt 16pt
Input Input Input
X0 X10 X20 X40
– – –
X7 X17 X37 X57
V40400
V40401
MSB
X X X
3 3 2
7 0 7
F4–04ADS
8pt 16pt 8pt
Input Input Input
X0 X10 X30 X40
– – –
X7 X27 X37 X57
LSB MSB
X X
2 1
0 7
16pt 16pt 16pt
Input Output Output
–
V40402
LSB
X
2
0
16pt 16pt 16pt
Input Output Output
–
V40400
LSB
X X X
1 7 0
0
4–9
