  • Page 1 WinPLC and Serial I/O Module Installation and Operation Manual Number: H2-WPLC-M...
  • Page 2 Notes...
  • Page 3 Errata Sheet Errata Sheet This Errata Sheet contains corrections or changes made after the publication of this manual. Date: 11 April 2019 Product Family: DL205 Manual Number: H2-WPLC-M Revision and Date: 4th Edition; May 2011 Change to Page 1-3 Currently States: “The operating system is resident in the module and does not require battery back-up.
  • Page 4 WARNING Thank you for purchasing automation equipment from Automationdirect.com ® , doing business as, AutomationDirect. We want your new automation equipment to operate safely. Anyone who installs or uses this equipment should read this publication (and any other relevant publications) before installing or operating the equipment.
  • Page 5 AVERTISSEMENT Nous vous remercions d'avoir acheté l'équipement d'automatisation de Automationdirect.comMC, en faisant des affaires comme, AutomationDirect. Nous tenons à ce que votre nouvel équipement d'automatisation fonctionne en toute sécurité. Toute personne qui installe ou utilise cet équipement doit lire la présente publication (et toutes les autres publications pertinentes) avant de l'installer ou de l'utiliser.
  • Page 6 DL205 W PLC USER M NU L Please include the Manual Number and the Manual Issue, both shown below, when communicating with Technical Support regarding this publication. Manual Number: H2-WPLC-M Issue: 4th Edition Issue Date: 5/11 Publication History Issue Date Description of Changes 1st Edition 4/99...
  • Page 7 Notes...

  • Page 8: Table Of Contents

    ABLE OF ONTENTS Chapter 1: Getting Started ........1–1 Manual Overview .
  • Page 9 Table of Contents Setting Up the WinPLC ..........1–12 Diagnosing Network Cable Problems .
  • Page 10 Table of Contents Setting The Serial Port Parameters ........3–8 Expand The Window Pane .
  • Page 11 Notes...
  • Page 12 HAPTER HAPTER HAPTER ETTING TARTED In This Chapter... • Manual Overview ........1–2 •...

  • Page 13: Chapter 1: Getting Started

    Getting Started Manual Overview Overview of this Publication The WinPLC and Serial I/O manual describes the installation of the modules, port configuration, power budgeting, and basic operation of the WinPLC and Serial I/O modules. There is also a brief discussion of Ethernet cabling issues.

  • Page 14: Winplc Overview

    Getting Started WinPLC Overview The WinPLC (part number H2-WPLC1-xx) is an open-platform CPU running the Windows→ CE operating system. It plugs into the CPU-slot of a irectLOGIC DL205 base and “talks” across the backplane to standard digital and analog input and output modules. The Windows→...

  • Page 15: The Winplc Leds

    Getting Started The WinPLC LEDs The WinPLC module has four LED indicator lights. The green POWER and RUN LEDs are individually addressable. Their exact meaning will depend on the PC-based Control software you are using. The green LINK LED has a double function. It indicates that the unit is connected successfully to an Ethernet network, and it indicates that there is activity on the network.

  • Page 16: Dl205 Power Wiring And Grounding

    Getting Started DL205 Power Wiring and Grounding The DL205 power supply is an integral part of the base. The DL205 also has three power options: 12/24VDC, 125VDC, and 120/240VAC. The diagram shows the terminal connections located on the power supply of the DL205 bases. The base terminals can accept up to 16 AWG.

  • Page 17: 10Baset Network Cabling

    Getting Started 10BaseT Network Cabling The H2–WPLC1–xx supports the Ethernet 10BaseT standard. The 10BaseT standard uses twisted pairs of copper wire conductors. 10BaseT Connections H2-WPLC-xx The H2-WPLC1-xx has an eight-pin modular jack that accepts RJ45 connector plugs. UTP (Unshielded Twisted- Pair) cable is rated according to its data-carrying ability (bandwidth) and is given a “category”...

  • Page 18: Maximum Ethernet Cable Length

    Getting Started Maximum Ethernet Cable Length The maximum distance per 10BaseT cable segment is 100 meters or 328 feet. Repeaters extend the distance. Each cable segment attached to a repeater can be up to 100 meters. Two repeaters connected together extend the total range to 300 meters. 10BaseT Distance Limitations 100 meters 100 meters...

  • Page 19: Power Budget For The Dl205 With H2-Wplc1-Xx

    Getting Started Power Budget for the DL205 with H2-WPLC1-xx Managing your Power Resource When determining which I/O modules you will be using in the DL205 WinPLC system, it is important to remember that there is a limited amount of power available from the power supply. We have provided a table showing the power available from the various DL205 base power supplies and a table showing the maximum power consumed by the WinPLC and each of the I/O modules supported by the WinPLC.

  • Page 20: Dl205 Module Power Requirements

    Getting Started DL205 Module Power Requirements The chart below shows the maximum amount of electrical current required to power each of the DL205 WinPLC or I/O modules. Use these values when calculating the power budget for your system. The Power Budget for the DL205 with H2--WPLC1--xx Power Consumed Power Consumed...

  • Page 21: Power Budget Calculation Example

    Getting Started Power Budget Calculation Example The following example shows how to calculate the power budget for the DL205 system. Auxiliary Base # Module Type 5 VDC (mA) Power Source 24 VDC Output (mA) Available Base Power D2–09B–1 2600 CPU Slot H2-WPLCxx + 480 Slot 0...

  • Page 22: Power Budget Calculation Worksheet

    Getting Started Power Budget Calculation Worksheet This blank chart is provided for you to copy and use in your power budget calculations. Auxiliary Base # Module Type 5 VDC (mA) Power Source 24 VDC Output (mA) Available Base Power CPU Slot Slot 0 Slot 1 Slot 2...

  • Page 23: Locating The Ethernet Address Label

    Getting Started Locating the Ethernet Address Label Ethernet Address Factory-assigned Ethernet Address A unique Ethernet Address is assigned to each (MAC Address) module at the factory and cannot be changed. It is a twelve digit number (six pairs of hexadecimal numbers) and is printed on a label permanently attached to the WinPLC module.

  • Page 24: Diagnosing Network Cable Problems

    Getting Started Diagnosing Network Cable Problems If you are experiencing communication problems, swapping cables is one of the simplest diagnostic procedures you can perform. If the network operates correctly with a different cable, you have isolated and cured the problem. If possible, use a short run of cable to test the network because problems with longer cable runs can be more difficult to diagnose and are more often intermittent.
  • Page 25 Getting Started Notes 1–14 WinPLC and Serial I/O Module Installation and Operation, 4th Edition...

  • Page 26: Chapter 2: Workbench Utility Operation

    HAPTER HAPTER HAPTER ORKBENCH TILITY PERATION In This Chapter... • WinPLC Workbench Overview ......2–2 •...

  • Page 27: Winplc Workbench Overview

    Workbench Utility Operation WinPLC Workbench Overview WinPLC Workbench is a utility to configure and check out a WinPLC I/O system. It is also used to load new ROM images on the WinPLC. Use Workbench with a new WinPLC to set its IP address, thereby allowing other devices or software products to connect with the WinPLC.

  • Page 28: Catching The Winplc: Using Workbench To Find Your Winplc Using Its Ethernet (Mac) Address

    Workbench Utility Operation Catching the WinPLC: Using Workbench To Find Your WinPLC Using its Ethernet (MAC) Address The “Catch” feature can find a WinPLC by its Ethernet Address (MAC Address). This Factory- address is found on the WinPLC label and assigned is set at the factory and cannot be changed.

  • Page 29: Setting The Tcp/Ip Communications

    Workbench Utility Operation Workbench has found your WinPLC and it’s Ethernet address appears in the “WinPLC” window. The green RUN LED should also be flashing. If you have problems, check to make sure you have the correct Ethernet address entered and that the IPX/SPX protocol is loaded on your PC.
  • Page 30 Workbench Utility Operation Scan for WinPLCs Monitor I/O Node Address Settings Now that that the IP address is set, Workbench should be able find the WinPLC automatically if it is run after the WinPLC is powered up and connected. If the WinPLC is connected after Workbench is running, just click on “Scan for WinPLCs”.
  • Page 31 Workbench Utility Operation Startup Settings Restore Default Settings “Startup Settings” are only used by the H2-WPLC1 and H2-WPLC2 models for C and VB programming. See H24- SDK-M for more information on these settings. Selecting “Restore Default Settings” returns the WinPLC to its factory default settings.

  • Page 32: Monitoring The I/O

    Workbench Utility Operation Following is a description of the utilities provided by Workbench. These programs allow you to monitor and test your I/O modules and your programming connection to the WinPLC without having to write a specific program. Monitoring the I/O Monitor I/O “Monitor I/O”...

  • Page 33: Discrete Input Modules

    Workbench Utility Operation Discrete Input Modules Below is an example where an 8 channel discrete input module has been selected. Notice that 8 blocks are displayed, each representing one channel. For discrete input modules, points that are ON will be blue, while points that are OFF will be black.

  • Page 34: Analog Input Modules

    Workbench Utility Operation Analog Input Modules Below is an example where a 4 channel analog input module has been selected. Notice that 4 blocks are illuminated, each representing one channel and displaying some non-zero digital value representing the sensed value. The exact digital value depends on the module resolution and range. For example, a 12 bit input module displays 4095 for a full-scale input.

  • Page 35: Test Applications Utility

    Workbench Utility Operation Test Applications Utility The “Run Test App” feature is only used by the H2-WPLC1 and H2-WPLC2 models for C and VB programming. See H24- SDK-M for more information. This utility lets you test your development PC’s ability to download a program to the WinLPLC and have the WinPLC run that program.
  • Page 36 I/O M HAPTER HAPTER ERIAL ODULE HAPTER & O NSTALLATION PERATION T & D . 6.0 SING LATER In This Chapter... • H2–SERIO(-4) Overview ....... .3–2 •...

  • Page 37: Chapter 3: Serial I/O Module Installation And Operation (Using T & D Ver. 6.0 Or Later)

    Serial I/O Module Installation and Operation H2–SERIO(-4) Overview The Scope of This Chapter This chapter introduces the use of the H2-SERIO and H2-SERIO-4 modules using the WinPLC with Think & Do, version 6.0 or later). See Appendix B if you are using Think & Do versions 5.2 or 5.3.

  • Page 38: Setting Communication Parameters Using Think & Do

    Serial I/O Module Installation and Operation Setting Communication Parameters Using Think & Do Use I/O View to set baud rate, parity, data bits, and stop bits for each port. Choose from 1200 to 115,200 baud communication speeds. Think & Do allows each port to be designated as a MODBUS slave or a generic serial device.

  • Page 39: H2-Serio(-4) Wiring: Rs-232

    Serial I/O Module Installation and Operation H2-SERIO(-4) Wiring: RS-232 RS 232 H2-SERIO(-4) RS-232 Pin Descriptions 6 pin RJ12 Phone Power (-) connection (GND) Type Jack – both ports CTS Clear to Send RXD Receive data (RS-232) TXD Transmit data (RS-232) RTS Request to Send Signal Ground (GND) NOTE: The serial port on-board the WinPLC has a different pinout from the H2–SERIO module.

  • Page 40: Using Think & Do To Set Serial Port Parameters

    Serial I/O Module Installation and Operation Using Think & Do to Set Serial Port Parameters Installing the H2-SERIO(-4) Install the WinPLC and the H2–SERIO(-4) module in your DL205 base. Please refer to the guidelines elsewhere in this publication for information about installation, power wiring, and Ethernet connections.

  • Page 41: Using Think & Do Connectivitycenter To Set Up The Serial I/O Module

    Serial I/O Module Installation and Operation Using Think & Do ConnectivityCenter to Set Up The Serial I/O Module ConnectivityCenter is the Think & Do tool for configuring I/O devices. See the Think & Do Studio Learning Guide (Chapter 2) for more detailed information on using ConnectivityCenter.

  • Page 42: Connecting To The Winplc

    Serial I/O Module Installation and Operation Connecting To The WinPLC To connect to the WinPLC, click “Configuration”, and select “Connect”. Think & Do recognizes the DL205 base as you have configured it. The WinPLC is displayed in the CPU slot, and the Serial I/O module is displayed where you have installed it.

  • Page 43: Setting The Serial Port Parameters

    Serial I/O Module Installation and Operation Setting Serial Port Parameters To set the serial port parameters, click on the “Serial Driver” in the left pane of the ConnectivityCenter window. You will see a port configuration box for each serial port Think &...
  • Page 44 ESP U PPENDIX PPENDIX HAPTER SING TILITY SING HINK & D . 5.2 O VER In This Appendix... • Using the Think & Do ESP Utility to Set Up the WinPLC ..A–2 Note: This Appendix only applies if you are using the WinPLC with Think & Do versions 5.2 or 5.3. Use Chapter 2 if using the WinPLC with Think &...

  • Page 45: Using The Think & Do Esp Utility To Set Up The Winplc

    Using The ESP Utility In Think & Do Vers. 5.2 or 5.3 Using the Think & Do ESP Utility to Set Up the WinPLC Check Think & Do Version First You will need Version 5.2 (or later) of Think & Do, to recognize the H2–SERIO module.

  • Page 46: Targetpicker

    Using The ESP Utility In Think & Do vers. 5.2 or 5.3 TargetPicker A “TargetPicker” message box opens to notify you that no CE targets are currently visible on the network. Acknowledge this message by clicking OK, and the “Think &Do ESP CE Station Selection”...

  • Page 47: Winplc Name Is Required

    Using The ESP Utility In Think & Do Vers. 5.2 or 5.3 WinPLC Name is Required The “Reset CE Runtime using IPX protocol” window requires you to name the WinPLC module. You can use up to 15 alphanumeric characters. If the name you select does not conform to the length or character usage requirements, you will see the TargetPicker error message shown below You can also assign an optional description...

  • Page 48: Cycle Power After Assigning Ip Address

    Using The ESP Utility In Think & Do vers. 5.2 or 5.3 Cycle Power After Assigning IP Address A TargetPicker message box will pop up to let you know you must cycle power to make the new IP address effective. After you click OK and cycle power to the DL205, the “Think &...
  • Page 49 Getting Started Notes –6 WinPLC and Serial I/O Module Installation and Operation, 4th Edition...
  • Page 50 I/O M PPENDIX ERIAL ODULE PPENDIX NSTALLATION PERATION T&D . 5.2 SING In This Appendix... • H2–SERIO(-4) Overview ....... .B–2 •...

  • Page 51: H2-Serio(-4) Overview

    Serial I/O Module Installation and Operation H2–SERIO(-4) Overview The Scope of This Appendix This chapter introduces the use of the H2-SERIO and H2-SERIO-4 modules using the WinPLC with Think & Do versions 5.2 or 5.3. This chapter will not describe in detail how to build a project or connect to a WinPLC.

  • Page 52: Setting Communication Parameters Using Think & Do

    Serial I/O Module Installation and Operation Setting Communication Parameters Using Think & Do Use I/O View to set baud rate, parity, data bits, and stop bits for each port. Choose from 1200 to 115,200 baud communication speeds. Think & Do allows each port to be designated as a MODBUS slave or a generic serial device.

  • Page 53: H2-Serio(-4) Wiring: Rs-232

    Serial I/O Module Installation and Operation H2-SERIO(-4) Wiring: RS-232 RS 232 H2-SERIO(-4) RS-232 Pin Descriptions 6 pin RJ12 Phone Power (-) connection (GND) Type Jack – both ports CTS Clear to Send RXD Receive data (RS-232) TXD Transmit data (RS-232) RTS Request to Send Signal Ground (GND) NOTE: The serial port on-board the WinPLC has a different pinout from the H2–SERIO module.

  • Page 54: Using Think & Do To Set Serial Port Parameters

    Serial I/O Module Installation & Operation When Using T & D Ver. 5.2 or 5.3 Using Think & Do to Set Serial Port Parameters Check Think & Do Version First You will need Version 5.2 of Think & Do, to recognize the H2–SERIO(-4) module.

  • Page 55: Connecting To The Winplc

    Serial I/O Module Installation & Operation When Using T & D Ver. 5.2 or 5.3 Notice in I/O View that the drivers for the DL205 backplane and the WinPLC serial port are already loaded. You will see them graphically represented in the left pane of the I/O View window.
  • Page 56 Serial I/O Module Installation & Operation When Using T & D Ver. 5.2 or 5.3 Click on the Serial Driver in the left pane of the I/O View window. You will see a port configuration box for each serial port Think & Do recognizes.

  • Page 57: Setting Serial Port Parameters

    Serial I/O Module Installation & Operation When Using T & D Ver. 5.2 or 5.3 Setting Serial Port Parameters To set the serial port parameters, click on the Serial Driver in the left pane of the I/O View window. You will see a port configuration box for each serial port Think &...
