Selecting Special Signal Ranges - Automation Direct DL405 User Manual

Selecting Special
Signal Ranges
Commonly Used Signal Ranges (continued)
Unipolar Signal Range
4 to 20 mA
0 to +5 VDC
0 to +10 VDC
The F4–04DA module supports additional ranges that are not encountered very
often. The following table shows the jumper selections for these ranges.
Signal Range
–10 to 0 VDC
–5 to 0 VDC
–2.5 to 0 VDC
$1.25 VDC
Table is continued on the next page.
F4–04DA 4-Channel Analog Output
Current Jumper
Installed
Current Jumper
Installed
12–5
Current Jumper
Removed
Not supported
with current
jumper removed
Current Jumper
Removed
Not supported
with current
jumper removed
Not supported
with current
jumper removed
Not supported
with current
jumper removed
Not supported
with current
jumper removed
