11–8
D4-02DA 2-Channel Analog Output
Output Bit
Assignments
You may recall the D4–02DA module requires 32 discrete output points. These 32
points provide the digital representation of the analog signals.
Since all output points are automatically mapped into V-memory, it is very easy to
determine the location of the data word that will be assigned to the module.
V40502
MSB
Bit 15 14 13 12 11 10 9 8 7 6
Y Y Y
5 5 4
7 0 7
Within these two word locations, the individual bits represent specific information
about the analog signal.
D4–02DA
8pt 8pt 32pt
Output Output Output
Y0 Y10 Y20
– – –
Y7 Y17 Y57
V40500
LSB MSB
5 4 3 2 1 0 Bit 15 14 13 12
Y Y
4 3
0 7
16pt 16pt 16pt
Output Input Input
Y60
–
Y77
V40503
V40501
LSB
11 10 9 8 7 6 5 4 3 2 1
Y Y Y
3 2 2
0 7 0
0
