Selecting the The jumpers labeled +1, +2, +4 and +8
Number of are used to select the number of
Channels channels that will be used.
Any unused channels are not processed
so if you only select channels 1–8, then
the last eight channels will not be active.
The
jumpers to install.
Channel(s) Channel(s)
1
1 2
1 2 3
1 2 3 4
1 2 3 4 5
1 2 3 4 5 6
1 2 3 4 5 6 7
1 2 3 4 5 6 7 8
Selecting Input The following table shows the jumper selections for the 5V and 10V ranges. The
module comes from the factory set for the 10V operation (jumpers installed). See
Signal Ranges
note below.
0 to +5 VDC
Jumpers OFF
0 to +10 VDC
Jumpers ON
NOTE: The jumpers do not have to both be set On or Off (e.g. Channels 1–8 can
be selected for 5V and Channels 9–16 can be selected for 10V operation).
F4–16AD–2 16-Channel Analog Input
following table shows
Jumper
+8 +4 +2 +1
No No No No
No No No Yes
No No Yes No
No No Yes Yes
No Yes No No
No Yes No Yes
No Yes Yes No
No Yes Yes Yes
Signal Range
which
Jumpers installed as shown
selects 16-channel operation
Channel(s) Channel(s)
1 2 3 4 5 6 7 8 9
1 2 3 4 5 6 7 8 9 10
1 2 3 4 5 6 7 8 9 10 11
1 2 3 4 5 6 7 8 9 10 11 12
1 2 3 4 5 6 7 8 9 10 11 12 13
1 2 3 4 5 6 7 8 9 10 11 12 13 14
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
1 2 3 4 5 6 7 8 9 10 11 12 13141516
Jumper Settings
Channels 1–8
Jumper
Channels 1–8
Jumper
7–5
+8 +4 +2 +1
Number of
Channels
Jumper
+8 +4 +2 +1
Yes No No No
Yes No No Yes
Yes No Yes No
Yes No Yes Yes
Yes Yes No No
Yes Yes No Yes
Yes Yes Yes No
Yes Yes Yes Yes
Channels 9–16
Jumper
Channels 9–16
Jumper
