The following table provides the specifications for the F4–04DA Analog Output
Module. Review these specifications to ensure the module meets your application
requirements.
Output
Number of Channels
Specifications
Output Ranges
Resolution
Conversion Method
Output Type
Output Impedance
Load Impedance
Maximum Load / Voltage
Voltage Output Current
Short-Circuit Current
Linearity Error
Gain Calibration Error
Offset Calibration Error
Conversion Time
General Module
Digital Output Points Required
Specifications
Power Budget Requirement
External Power Supply
Accuracy vs. Temperature
Operating Temperature
Storage Temperature
Relative Humidity
Environmental air
Vibration
Shock
Noise Immunity
One count in the specification table is equal to one least significant bit of the analog data value (1 in 4096).
F4–04DA 4-Channel Analog Output
4
0–5V, 0–10V, $5V, $10V, 4–20 mA
12 bit (1 in 4096)
Successive Approximation
Single ended, 1 common
0.2Ω typical, voltage output
2KΩ minimum, voltage output
0Ω minimum, current output
680Ω/18V, 1KΩ/24V, 1.5KΩ/36V,
current output
5 mA sink or source
15 mA typical, voltage output
$1 count ($0.025%) maximum
$8 counts maximum, voltage output
–8 to +11 counts maximum, current output
$2 counts maximum, voltage output
–5 to +9 counts maximum, current output
5 ms maximum, settling time
0.3 ms maximum, digital out to analog out
16 point (Y) outputs,
12 bits binary data, 4 channel select bits
120 mA @ 5 VDC (from base)
24 VDC, 100 mA, class 2 $10%
(add 20 mA for each current loop used)
$50 ppm / _C maximum full scale
$25 ppm / _C maximum offset
0 to 60_C (32 to 140°F)
–20 to 70_C (–4 to 158°F)
5 to 95% (non-condensing)
No corrosive gases permitted
MIL STD 810C 514.2
MIL STD 810C 516.2
NEMA ICS3-304
