The following tables provide the specifications for the F4–08DA–2 Analog Voltage
Output Module. Review these specifications to ensure the module meets your
application requirements.
Output
Number of Channels
Specifications
Output Range
Resolution
Output Type
External Load
Crosstalk
Linearity Error (end-to-end)
and Relative Accuracy
Full Scale Calibration Error
(offset error included)
Offset Calibration Error
Maximum Inaccuracy
Conversion Time
General Module
Digital Output Points Required
Specifications
Power Budget Requirement
External Power Supply
Accuracy vs. Temperature
Operating Temperature
Storage Temperature
Relative Humidity
Environmental Air
Vibration
Shock
Noise Immunity
F4–08DA–2 8-Ch. Analog Voltage Output
8, single ended (one common)
0–5VDC, 0–10VDC
12 bit (1 in 4095)
Voltage Sourcing 10mA max.
1kΩ maximum / 10kΩ minimum
(for example: 10 volts at 1kΩ = 10mA load;
10 volts at 10kΩ = 1mA load)
–70 dB, ±1 count maximum
±1 count maximum (10VDC at 25°C)
±6 counts maximum (10VDC at 25°C)
±3 counts maximum (0VDC at 25°C)
±0.2% at 25°C (77°F)
±0.4% at 0° to 60°C (32° to140°F)
400 mS maximum, for full scale change
4.5 to 9 mS for digital output to analog out
16 point (Y) outputs,
12 bits binary data, 3 bits channel select,
1 bit output enable
80 mA at 5 VDC (supplied by base power
supply)
21.6 to 26.4 VDC, 150 mA max., class 2
±57 ppm / °C full scale calibration range
(including maximum offset change, 2 counts)
0° to 60°C (32° to 140°F)
–20° to 70°C (–4° to 158°F)
5 to 95% (non-condensing)
No corrosive gases permitted
MIL STD 810C 514.2
MIL STD 810C 516.2
NEMA ICS3-304
