5–4
F4–08AD 8-Channel Analog Input

Setting the Module Jumpers

Jumper
Locations

Jumper Locations

Selecting the
Number of
Channels
If you examine the rear of the module, you will notice four banks of jumpers. The
module has several options that you can select by installing or removing these
jumpers:
S
A bank of eight jumpers to set voltage or current input for each
channel.
S
A bank of four jumpers to select the signal range for all active channels.
S
A bank of three jumpers to select the number of channels used.
S
A bank of two jumpers to select unipolar or bipolar signal range for all
active channels.
The module is set at the factory for a 4–20 mA signal range on all eight channels
with unipolar polarity. The following diagram shows how the jumpers are set at the
factory and describes the function of each jumper. When removing a jumper, store it
by placing it on a single pin to prevent losing it.
Voltage or Current Selection
For Each Channel
1 2 3
Jumper on = Current
+4 +2 +1
Number of
Channels
The jumpers labeled +1, +2 and +4 are
used to select the number of channels
that will be used.
Any unused channels
processed. For example, if you only
select the first four channels, then the
last four channels will not be active. Use
this table to determine jumper settings.
Number of Yes = jumper installed
No = jumper removed
Channels
Selected +4 +2
1 No No
2 No No
3 No Yes
4 No Yes
5 Yes No
6 Yes No
7 Yes Yes
8 Yes Yes
Signal Range
4 5 6 7 8
off = Voltage
are not
Jumpers installed as
+1
shown selects 8-channel
No
operation.
Yes
For example: To select
No
3-channel operation, remove
Yes
the +4 and +1 jumpers and
No
install the +2 jumper.
Yes
No
Yes
Selection
BI UNI
Polarity
+4 +2 +1
Number of
Channels
