Writing the Control Program
If you have configured the F4–08AD module, use the following examples to get
started writing the control program.
Multiple
Since all channels are multiplexed into a single data word, the control program must
Channels
be set up to determine which channel is being read. Since the module appears as X
Selected
input points to the CPU, it is very easy to use the active channel status bits to
determine which channel is being monitored.
F4–08AD 8-Channel Analog Input
F4-08AD
8pt
8pt
Input
Input
X0
X10
–
–
X7
X17
V40400
V40401
MSB
Active
Unusable
Channel Bits
Bit
16pt
16pt
16pt
16pt
Input
Input
Output
Output
X20
X40
–
–
X37
X57
V40402
LSB
Data Bits
5–13
