Module Operation

D4–430 Special Even though the module can be placed in any slot, it is important to examine the
Requirements configuration if you are using a D4–430 CPU. As you will see in the section on
writing the program, you use V-memory locations to extract the analog data. As
shown in the following diagram, if you place the module so the input points do not
start on a V-memory boundary, the instructions cannot access the data.
Correct!
Wrong!
Data is split over two locations, so instructions cannot access data from a D4–430.
V40401
MSB
X X X
3 3 2
7 0 7
F4–16AD–2 16-Channel Analog Input
F4–16AD–2
8pt 8pt 16pt 16pt
Input Input Input Input
X0 X10 X20 X40
– – – –
X7 X17 X37 X57
V40400 V40402
V40401
MSB
X X X
3 3 2
7 0 7
F4–16AD–2
8pt 16pt 8pt 16pt
Input Input Input Input
X0 X10 X30 X40
– – – –
X7 X27 X37 X57
LSB MSB
X X
2 1
0 7
16pt 16pt
Output Output
LSB
X
2
0
16pt 16pt
Output Output
V40400
LSB
X X X
1 7 0
0
7–9
