Summary of Contents for Automation Direct DL405
- Page 1 Introduction In This Section..— Overview — DCM Hardware — Applications — Specifications — Using the DCM – Five Steps...
- Page 2 DCM as an extra general purpose communication port for your DL405 PLC system. If you plan on using the DCM as a network master or slave on a Direct NET network, we suggest that you read the Direct NET manual first.
- Page 3 Introduction Steps The main contents of this manual are organized into five steps: tells you about the Data Communication Module and its Introduction uses. It lists other manuals you may need and tells you how to get additional technical assistance, if necessary. guides you through building the necessary communication Build the Cable cable, covering physical and electrical specifications.
- Page 4 ON if master OFF if slave DCM Uses The DL405 Data Communications Module (DCM) is a general purpose communications interface for the DL405 family of Programmable Logic Controllers (PLCs). This module is primarily used for three reasons. As a network interface to a Direct NET network...
- Page 5 Using a DCM as part of a PLC Network Slave — The DCM can also be used in a DL405 PLC station that is serving as a network slave station. In this case, the DCM “listens” to the network for any messages that contain the DCM’s address. The DCM deciphers the network commands, carries out the request to read or write data, and sends confirmation and/or information to the master station.
- Page 6 DL405 PLCs. Plus, the DCM can communicate at higher baud rates. If Port you can connect a device to the bottom port on the DL405 PLC, then you can also connect the same device to the DCM. These devices can be a variety of things, such as operator interfaces or personal computers.
-
Page 7: Specifications
Introduction Specifications Environmental Specifications Operating Temperature 32 F to 140 F (0 to 60 C) Storage Temperature –4 F to 158 F (–20 to 80 C) Operating Humidity 5 to 95% (non-condensing) Air Composition No corrosive gases permitted MIL STD 810C 514.2 Vibration MIL STD 810C 516.2 Shock... - Page 8 Introduction Using your DCM– Five Steps Complete the following steps to connect the DCM. STEP 1. Familiarize yourself with the communications options of DCM in the Introduction. Cable STEP 2. Build the communication cable that fits your needs. Switches STEP 3. Set the DCM switches. (Baud rate, parity, etc).
