Load Each channel can be wired independently for voltage or current. However, you
cannot use both "10 VDC and 4–20 mA signals on the same module.
Requirements
Removable The F4–04DA module has a removable connector to make wiring easier. Simply
remove the retaining screws and gently pull the connector from the module.
Connector
Wiring Diagram
User Wiring
CH1
2K ohms
Min.
CH2
2K ohms
Min.
CH3
0–1K ohms
CH4
0–1K ohms
Transmitter
S
Current loads must have an impedance between 0 and 1000 ohms.
S
Voltage loads must have an impedance greater than 2K ohms.
NOTE 1: Shields should be connected to the 0V terminal of the module or power supply.
NOTE 2: Unused voltage and current outputs should remain open (no connections).
See NOTE 1
CH1 –I
CH1 –V
Voltage Output
CH2 –I
CH–V
Current
CH3 –I
Output
CH3 –V
Current
CH4 –I
Output
CH4 –V
0V
Supply
User
Supply
18–30 VDC
21.6–26.4 VDC
F4–04DA 4-Channel Analog Output
Internal module circuitry
CH1 +I
4–20mA curr. sinking
CH1 +V
volt. sink/source
CH2 +I
4–20mA curr. sinking
CH2 +V
volt. sink/source
CH3 +I
4–20mA curr. sinking
CH3 +V
volt. sink/source
CH4 +I
4–20mA curr. sinking
CH4 +V
volt. sink/source
24V
12–7
ANALOG OUTPUT
F4-04DA
0-10VDC
D/A
0-5VDC
$10VDC
$5VD
4mA-20mA
CH1
+I
CH1
D/A
-I
CH1
+V
CH1
–V
CH2
+I
CH2
D/A
–I
CH2
+V
CH2
–V
CH3
+I
CH3
D/A
–I
CH3
+V
CH3
–V
CH4
+I
CH4
–I
CH4
+V
CH4
–V
24VDC 0.1A
24
V
0
V
