16–8
F4–16DA–1 16-Ch. Analog Current Output
Output Bit
Assignments
You may recall the F4–16DA–1 module requires 32 discrete output points from the
CPU. These points provide:
S
The digital representation of two analog signals per scan.
S
Identification of the two channels that are to receive the data.
S
Output enable control for all channels.
Since all output points are automatically mapped into V-memory, it is very easy to
determine the location of the two data words that will be assigned to the module.
V40502
MSB
Bit 15 14 13 12 11 10 9 8 7
Y Y Y
5 5 4
7 0 7
Channels 9–16
Within these V-memory locations the individual bits represent specific information
about the channels selected and the analog signals.
F4–16DA–1
8pt 8pt 32pt 16pt
Output Output Output Output
Y0 Y10 Y20 Y60
– – – –
Y7 Y17 Y57 Y77
V40500 V40503
LSB MSB
6 5 4 3 2 1 0 Bit 15 14 13
Y Y
4 3
0 7
16pt 16pt
Input Input
V40501
LSB
12 11 10 9 8 7 6 5 4 3 2 1
Y Y
3 2
0 7
Channels 1–8
0
Y
2
0
