Communucation Connector Module DN-25TB
Cables and PLC Modules
PLC Type
Cable Type
DL305
ZL-DN25TB-CBL
DL405
ZL-DN25TB-CBL
Application Note: DN-25TB for use in end-of-run wiring applications (point-to-point) only.
Not for use in middle station applications, such as in a multi-drop network.
WARNING : WIRE ONLY ACCORDING TO WIRING DIAGRAMS SHOWN BELOW TO
AVOID CAUSING DAMAGE TO THE PLC OR CONNECTOR MODULE. MATCH THE
CORRECT COMBINATION OF CABLE, PLC I/O MODULE, AND CONNECTOR MODULE AS SHOWN.
Wiring Diagram: Outputs
PLC DL 305
Type D3-350CPU
DN25TB
To download fullsize color .pdf Ziplink Wiring Diagrams
go to
www.Automationdirect.com
PLC Module Type
D3-350CPU
D4-450CPU
website
Connector Module Type
DN-25TB
DN-25TB
DN25TB
TERMINAL BLOCK
Pg. 1
Cable ZL-DN25TB-CBL
Terminal
DSub 25-P
Block 25-P
1
A1
2
A2
3
A3
4
A4
5
A5
6
A6
7
B3
8
A7
9
B4
10
B1
11
C5
12
A8
13
A9
14
B5
15
B6
16
B2
17
B7
18
C1
19
C4
B8
20
B9
21
C6
22
C2
23
C7
24
25
C8
TM
REV 1.2
Advertisement
Table of Contents
Related Manuals for Automation Direct DL305
Summary of Contents for Automation Direct DL305
- Page 1 Communucation Connector Module DN-25TB Cables and PLC Modules PLC Type Cable Type PLC Module Type Connector Module Type DN-25TB DL305 ZL-DN25TB-CBL D3-350CPU DL405 ZL-DN25TB-CBL D4-450CPU DN-25TB Application Note: DN-25TB for use in end-of-run wiring applications (point-to-point) only. Not for use in middle station applications, such as in a multi-drop network.
- Page 2 Wiring Diagram: Outputs PLC DL 405 Type D4-450CPU Cable ZL-DN25TB-CBL Terminal DSub 25-P Block 25-P TERMINAL BLOCK DN25TB Connecting RS232 DIP SWITCH CONFIGURATION A2 A3 A4 A5 RS 232 Configuration 1 2 3 4 RS 232 PORT 1 DL 305 D3-350 PORT 1 DL 405 D4-450 PORT 1 DL 405 D4-430 PORT 1 DL 405 D4-440...
- Page 3 Connecting RS422 DIP SWITCH CONFIGURATION C1 C2 C4 C5 RS 422 Configuration B2 B3 B4 B5 1 2 3 4 RS 422 with 120 ohm resistor RXD+ -------- RXD- 1 2 3 4 RS422 without 120 ohm resistor RXD+ -------- RXD- Remote I/O Configuration 1 2 3 4 Remote I/O without...
