3 Mode No.
102 001 Serial Number
103 PSTN-1 Port Settings
001 Select Line
002 PSTN Access
Number
003 Memory Lock
Disabled
107 IPFAX Port Settings
001 H323 Port
002 SIP Port
003 RAS Port
004 Gatekeeper port
005 T.38 Port
006 SIP Server Port
007 IP FAX Protocol
Priority
201 FAX SW
001 – 00 – 1F
032
301 Fax: FlairAPI Setting
101 -

SP4-XXX (ROM Versions)

4
101 001 FCU ROM Version
102 001 Error Codes
103 001 G3-1 ROM Version

SP5-XXX (RAM Clear)

5 Mode No.
101 001 Initialize SRAM
(except Secure)
102 001 Erase All Files
103 001 Reset Bit Switches
(except Secure)
Enter the fax unit's serial number.
Select the line type setting for the G3-1 line. If the machine is installed on a
PABX line, select "PABX", "PABX(GND)" or "PABX(FLASH)".
Enter the PSTN access number for the G3-1 line.
If the customer does not want to receive transmissions using Memory Lock on
this line, turn this SP on.
Sets the H323 port number.
Sets the SIP port number.
Sets the RAS port number.
Sets the Gatekeeper port number.
Sets the T.38 port number.
Sets the SIP port number.
Select "H323" or "SIP".
Mode No.
Initializes the bit switches and user parameters, user data in the SRAM, files in
the SAF memory, and clock.
Erases all files stored in the SAF memory.
Resets the bit switches and user parameters.
Function
Displays the FCU ROM version.
Displays the latest 64 fax error codes.
Displays the G3-1 modem version.
Function
4.Service Tables
Function
37
