Page 1 P C300W/C301W, M C250FWB/C250FW Machine Code: M0CS/M0CW/M0CX/M0CZ Field Service Manual Ver 1.0 Latest Release: July, 2019 Initial Release: July, 2019 (c) 2019 Ricoh Co.,Ltd.
Page 3 Important Safety Notices Warnings, Cautions, Notes In this manual, the following important symbols and notations are used. • A Warning indicates a potentially hazardous situation. Failure to obey a Warning could result in death or serious injury. • A Caution indicates a potentially hazardous situation. Failure to obey a Caution could result in minor or moderate injury or damage to the machine or other property.
Page 4 Safety Prevention of Physical Injury Before disassembling or assembling parts of the machine and peripherals, make sure that the machine and peripheral power cords are unplugged. The plug should be near the machine and easily accessible. Note that some components of the machine and the paper tray unit are supplied with electrical voltage even if the main power switch is turned off.
Page 5 small children. 19. For machines installed with the anti-tip components: The anti-tip components are necessary for meeting the requirements of IEC60950-1, the international standard for safety. The aim of these components is to prevent the products, which are heavy in weight, from toppling as a result of people running into or leaning onto the products, which can lead to serious accidents such as persons becoming trapped under the product.
Page 6 Handling Toner • Work carefully when removing paper jams or replacing toner bottles or cartridges to avoid spilling toner on clothing or the hands. • If toner is inhaled, immediately gargle with large amounts of cold water and move to a well- ventilated location.
Page 7 Laser Safety The Center for Devices and Radiological Health (CDRH) prohibits the repair of laser-based optical units in the field. The optical housing unit can only be repaired in a factory or at a location with the requisite equipment. The laser subsystem is replaceable in the field by a qualified Customer Engineer. The laser chassis is not repairable in the field.
Page 9 Symbols and Abbreviations This manual uses several symbols and abbreviations. The meaning of those symbols and abbreviations are as follows: Symbol What it means Clip ring Screw Connector Clamp E-ring Flexible flat cable (FFC) Timing belt Short edge feed Long edge feed Black Cyan Magenta...
Page 10 Trademarks Adobe and Acrobat are either registered trademarks or trademarks of Adobe Systems Incorporated in the United States and/or other countries. Android, Google Chrome, and Google Play are trademarks or registered trademarks of Google LLC. OS X, macOS, TrueType, App Store, and Safari are trademarks of Apple Inc., registered in the U.S. and other countries.
Page 11 • The product names of Windows Server 2008 are as follows: Microsoft® Windows Server® 2008 Standard Microsoft® Windows Server® 2008 Enterprise • The product names of Windows Server 2008 R2 are as follows: Microsoft® Windows Server® 2008 R2 Standard Microsoft® Windows Server® 2008 R2 Enterprise •...
Page 13: Table Of Contents
Table of Contents Product Information ........................... 7 Specifications ............................7 Machine Configuration .......................... 8 Main Machine ........................... 8 Optional Equipment .......................... 8 Installation ............................9 Installation Requirements ........................9 Environment ............................9 Machine level ............................ 9 Machine Space Requirements ......................10 Power Requirements ........................
Page 14 Laser Unit ............................52 Caution Decal Locations ......................... 52 Laser Unit ............................52 AIO (All In One) Cartridge ........................56 AIO Cartridge ..........................56 Black Drum Motor (M2) ........................56 Color Drum Motor (M1) ........................60 Image Transfer ........................... 62 Waste Toner Bottle .........................
Page 15 Paper Exit Roller ..........................95 Paper Exit Sensor (S5) ........................96 Paper End Sensor (S3) ........................97 Registration Sensor (S4) ......................... 98 Duplex Motor (M5) .......................... 98 Electrical Components ........................103 FCU (PCB8) (MF Model Only) ...................... 103 Speaker (MF Model Only) ......................104 Engine Board (EGB) (PCB1) ......................
Page 16 CTL SP ............................164 Test Pattern ..........................165 @Remote ............................166 Calibrating the LCD (MF Model Only) ....................169 Fax Service Test Menu (MF Model Only) ..................172 Print List/Report ..........................173 Types of Lists/Reports ........................173 Printing Reports ..........................173 Report Examples ..........................
Page 17 Spotted Images ..........................236 Uneven Color ..........................237 Other Causes of Dirty Copies ....................... 239 Problem at Regular Intervals ......................240 Irregular, Uneven Coverage ......................241 Abraded Images..........................241 Other Information ..........................243 Spurious Noise ..........................243 How to Confirm Information on the Toner ID Chip ................ 243 Machine Operation with Toner Level Alert ..................
Page 18 Image Fusing ............................ 276 Overview ............................276 Mechanism ........................... 276 Paper Feed ............................280 Overview ............................280 Mechanism ........................... 280 Paper Exit and Duplex ........................283 Overview ............................283 Mechanism ........................... 284 Boards .............................. 285 Block Diagram ..........................285 Board Outline ..........................286...
Page 19: Product Information
1.Product Information 1. Product Information Specifications See “Appendices” for the following information: • General Specifications • Supported Paper Sizes...
Page 20: Machine Configuration
1.Product Information Machine Configuration Main Machine Name Machine PPM (Single- Function Operation Area Code sided mode) Panel P C300W M0CS BW/FC: Printer 4–line LCD For EU/AA, 25ppm (A4/LT) Supported TWN, CHN P C301W M0CW BW/FC: Printer 4–line LCD For NA, EU/AA...
Page 21: Installation
2.Installation 2. Installation Installation Requirements Environment Temperature Range: 10°C to 32°C (50F to 89.6F) Humidity Range: 15% to 80% Rh Ambient Illumination: Less than 2,000 lux (do not expose to direct sunlight) Ventilation: 30 m /hr/person Do not put the machine in areas that get sudden temperature changes. This includes: •...
Page 22: Machine Space Requirements
2.Installation Machine Space Requirements Put the machine near the power source with these clearances: Printer Model [A]: Left side: Over 20 cm (7.9") [B]: Right side: Over 10 cm (4.0") [C]: Front: Over 70 cm (27.6") [D]: Rear: Over 20 cm (7.9") [E]: Top: Over 33 cm (13.0") MF Model [A]: Left side: Over 20 cm (7.9")
Page 23: Power Requirements
2.Installation [E]: Top: Over 24 cm (9.5") Power Requirements • Make sure that the plug is tightly inserted in the outlet. • Avoid multi-wiring. • Make sure the machine is grounded. Input voltage level 120 V to 127 V, 60 Hz: Less than 11 A (for North America) 220 V to 240 V, 50 Hz/60 Hz: Less than 6 A (for Europe/ Asia) 110 V, 60 Hz: Less than 12 A (for Taiwan) Permitted voltage fluctuation: 10%...
Page 24: Installation Procedure
2.Installation Installation Procedure Refer to the Quick Installation Guide for details about installing the machine.
Page 25: Settings For @Remote Service
2.Installation Settings for @Remote Service • Prepare the necessary equipment and check the following points before you visit the customer site. For details, ask the @Remote key person. • Make sure that the latest version of the firmware is installed on the machine. Check Points before Making @Remote Settings The following settings must be correctly programmed.
Page 26: Setting For Paas (Only For Chn)
2.Installation Printer model: SP menu > @Remote > Remote Service > Function Flag MF model: SP menu > @Remote > Remote Service > Function Flag Execute the @Remote Settings Enter the SP mode. Check if the @Remote status is "0". Printer model: SP menu >...
Page 27 2.Installation Center GUI. Printer model: @Remote > Remote Service > Instl:Ref Section MF model: @Remote > Remote Service > Confirm Place Execute the registration. Printer model: @Remote > Remote Service > Instl:Rgstltn MF model: @Remote > Remote Service > Register Execute Check the registration result.
Page 28 2.Installation Caused by Operation Error, Incorrect Setting Code Meaning Solution/ Workaround Attempted registration without execution of a Perform Confirmation before attempting 12003 confirmation and no previous registration. the Registration. Attempted setting with illegal entries for Check the ID2 of the machine. 12004 certification and ID2.
Page 29: Preventive Maintenance
3.Preventive Maintenance 3. Preventive Maintenance Preventive Maintenance See “Appendices” for the following information: • Preventive Maintenance...
Page 30: Cleaning Points
3.Preventive Maintenance Cleaning Points TM/P Sensor Open the upper cover. Remove the rearmost print cartridge, and then slide the TM/P sensor lever once to the left. Exposure Glass (Only MF Model) Open the ADF unit. Clean the parts indicated by arrows with a soft damp cloth, and then wipe the same parts with a dry cloth to remove any remaining moisture.
Page 31 3.Preventive Maintenance cloth to remove any remaining moisture. Close the ADF unit. Open the ADF cover. Clean the indicated parts with a soft damp cloth, and then wipe the same parts with a dry cloth to remove any remaining moisture. Registration Roller •...
Page 32 3.Preventive Maintenance Clean the registration roller with a soft damp cloth. Separation Pad, Paper Feed Roller Pull out the paper tray and remove the paper in the tray. Wipe the separation pad with a soft damp cloth. Wipe the paper feed roller with a soft damp cloth, and then wipe the same parts with a dry cloth to remove any remaining moisture.
Page 33 3.Preventive Maintenance Push the metal plate down until it clicks. Reload the removed paper into the tray, and then push the tray into the machine. Paper Tray Pull out the paper tray and remove the paper in the tray. Wipe the inside of the paper tray with a cloth. LD Unit Dust Shield Glass When image defects (vertical stripes) occur, clean if necessary.
Page 34 3.Preventive Maintenance to remove any remaining moisture.
Page 35: Image Quality Standards
3.Preventive Maintenance Image Quality Standards Printer Item Specification Remarks Assured Image Area Leading edge: 4.2 mm (1/6 inches) Envelopes Left/Right: 4.2 mm (1/6 inches) Leading edge: 15 mm Trailing edge: 4.2 mm (1/6 inches) Left/Right: 10 mm Trailing edge: 10 mm Magnification Error Main: ±...
Page 36: Paper Transfer Quality Standards
3.Preventive Maintenance Paper Transfer Quality Standards Printer Item Specification Remarks Registration Single Side: Reference value when using the Main Scan: 0 ± 2.0 mm bypass tray: Sub Scan: 0 ± 1.5 mm Main Scan: 0 ± 3.5 mm Duplex: Sub Scan: 0 ± 2.5 mm Main Scan: 0 ±...
Page 37: Replacement And Adjustment
4.Replacement and Adjustment 4. Replacement and Adjustment General Cautions • Turn off the main power switch and disconnect the power cord. • After replacement, make sure that all removed harnesses are connected again and secured in their clamps.
Page 38: Special Tools
4.Replacement and Adjustment Special Tools • PC: Windows 7/8.1/10 or Windows Server 2008/2008 R2/2012/2012 R2/2016. • USB cable • C-5Y Color Chart (Part number: VSST9003) C-5Y Color Chart is used during the adjustment after replacing the back CIS.
Page 39: Exterior Covers
4.Replacement and Adjustment Exterior Covers Rear Cover Printer Model Remove the rear tray cover [A] and the interface cover [B]. Remove the rear cover [A]. There are some hooks inside the rear cover. Slide upward to release the hooks, and then remove the rear cover.
Page 40 4.Replacement and Adjustment MF Model Remove the rear tray cover [A] and the interface cover [B]. Remove the rear cover [A]. There are some hooks inside the rear cover. Slide upward to release the hooks, and then remove the rear cover.
Page 41: Operation Panel
4.Replacement and Adjustment Operation Panel Open the top cover [A]. Open the front cover [A]. Remove the connector cover [A]. Remove the operation panel [A]. Printer model:...
Page 42 4.Replacement and Adjustment MF model: For the MF model only, disconnect the FFC [A] by lifting the operation panel. The FFC has a lock mechanism, so push the button to unlock it.
Page 43: Right Cover
4.Replacement and Adjustment Right Cover Remove the rear cover. (Rear Cover) Remove the operation panel. (Operation Panel) Remove the right cover [A]. Top front screw: M3 x 8, others: M4 x 10 Left Cover Open the top cover [A].
Page 44: Front Cover Unit
4.Replacement and Adjustment Open the front cover [A]. Release the hook and remove the left cover [A]. Top front screw: M3 x 8, others: M4 x 10 Front Cover Unit Remove the rear cover. (Rear Cover) Remove the operation panel. (Operation Panel) Remove the right cover.
Page 45 4.Replacement and Adjustment Release the belt [A], and then remove the front cover unit [B].
Page 46: Adf/Scanner Unit (Mf Model Only)
4.Replacement and Adjustment ADF/Scanner Unit (MF Model Only) ADF/Scanner Assembly The ADF unit and scanner unit are connected by an FFC [A], so they cannot be separated. Replace the ADF unit and scanner unit together as the ADF/Scanner Assembly. Remove the rear cover. (Rear Cover) Remove the controller box cover [A].
Page 47 4.Replacement and Adjustment Disconnect the three FFCs and pull out from the ferrite core [A]. Disconnect the three connectors. When disconnecting the connector [A], use a tool such as radio pliers to hold it. Press and hold the lock button [A], and then slide the scanner unit [B] in the direction of the blue arrow.
Page 48 4.Replacement and Adjustment Press and hold the lock button [A], close the top cover, and then slide the scanner unit [B] in the direction of the blue arrow. Open the top cover and remove the fixing screw [A]. • The fixing screw is a plastic screwing rivet. •...
Page 49 4.Replacement and Adjustment 10. Close the top cover. 11. While pressing the lock button [A], slide the scanner unit [B] in the direction of the blue arrow, and then remove it. Adjustment after Replacing the ADF/Scanner Assembly After replacing the ADF/scanner assembly, adjust the contact image sensor (CIS) for the front and back. Because of differences in each individual ADF/scanner assembly, go into the SP mode, and enter the values on the barcode on the assembly to adjust the difference in the color balance between front and back.
Page 50 4.Replacement and Adjustment Press [Scanner Service Setting]. Press [Image Adjust]. Select the following settings and set them to the values on the barcode. Setting Initial Range Description value (steps) Backside CIS-Red- -30 to 30 Adjusts the difference in color balance between White the front and back for red.
Page 51: Extension Tray/Original Tray
4.Replacement and Adjustment Setting Initial Range Description value (steps) White the front and back for blue. Backside CIS- -30 to 30 Adjusts the difference in color balance between Gray-White the front and back for gray. Extension Tray/Original Tray Open the extension tray [A], bend it slightly to disengage the hooks on the sides, and then remove Open the ADF cover, disengage the hooks on the sides of the original tray [A], and then remove the tray.
Page 52: Adf Front Cover
4.Replacement and Adjustment ADF Front Cover While pressing the ADF release bar [A] on the back of the scanner unit, open the ADF. Cover the scanner exposure glass with a mat or cloth to prevent it from being damaged. Open the ADF cover, and then remove the ADF front cover [A].
Page 53: Adf Rear Cover
4.Replacement and Adjustment ADF Rear Cover While pressing the ADF release bar [A] on the back of the scanner unit, open the ADF. Cover the scanner exposure glass with a mat or cloth to prevent it from being damaged. Remove the screws on the ADF rear cover. Remove the screw on the back of the scanner unit.
Page 54: Adf Separation Pad
4.Replacement and Adjustment Open the ADF cover, and then remove the ADF rear cover [A]. There are four hooks on the ADF rear cover. Be sure to disengage all the hooks when you remove the cover. ADF Separation Pad Open the ADF top cover. While pressing the parts indicated by red arrows, remove the ADF separation pad [A].
Page 55: Adf Feed Roller
4.Replacement and Adjustment ADF Feed Roller Open the ADF top cover. Bend the rib [A] out slightly and then remove the original feed unit [B]. Remove the ADF feed roller [A]. After the installation, make sure that the gears turn properly. ADF Pick-up Roller Open the ADF top cover.
Page 56: Transport Roller
4.Replacement and Adjustment Slide the ADF pick-up roller [A] towards the gear, and then remove it from the original feed unit. Work carefully because the gear contains a spring. Transport Roller While pressing the ADF release bar [A] on the back of the scanner unit, open the ADF. Cover the scanner exposure glass with a mat or cloth to prevent it from being damaged.
Page 57 4.Replacement and Adjustment Remove the cover for the transport roller [A]. Raise the transport roller shaft. Remove the ADF front cover. (ADF Front Cover) Remove the ADF rear cover. (ADF Rear Cover) Remove the screws at the front side of the ADF drive unit [A]. Lift the ADF drive unit [A] slightly, and then pull the transport roller shaft [B] out through the gap.
Page 58: Back Cis/Back Adf Exposure Glass
4.Replacement and Adjustment Open the ADF and then remove the springs and rollers. Back CIS/Back ADF Exposure Glass Remove the ADF front cover. (ADF Front Cover) Remove the ADF rear cover. (ADF Rear Cover) Open the ADF upper cover and then remove the back DF exposure glass [A]. To Remove the Back ADF Exposure Glass Press the hooks [A] at the sides of the back ADF exposure glass outward, insert your fingertips...
Page 59 4.Replacement and Adjustment through the gaps [B] and then push up the back ADF exposure glass [C]. Check that the hooks have been disengaged and then remove the back ADF exposure glass [B]. Remove the back CIS [A].
Page 60 4.Replacement and Adjustment After replacing the back CIS, adjust the difference in image quality between the front and back. (See Adjustment after Replacing the Back CIS.) To Attach the Back ADF Exposure Glass Position the back ADF exposure glass with the side with the tilt facing up to come in contact with the original.
Page 61 4.Replacement and Adjustment After changing the back CIS, enter the SP mode. Press [Scanner Service Setting]. Press [Image Adjust]. Check that the following settings are set to the initial value of "0". If not, change the values to “0”. Setting Initial Range/Steps Description...
Page 62 4.Replacement and Adjustment Check which is the applicable case from cases 1 to 4 below, and then enter the appropriate adjustment values. Examples: a) The image on the front is 'targeted gray', and the image on the back is 'greenish' Applicable to case 1.
Page 63 4.Replacement and Adjustment Image on the back Image on the front Targeted gray Reddish Greenish Bluish Green Blue Gray 10. After adjustment make a duplex color copy, and then confirm that the colors are the same on both sides.
Page 64: Laser Unit
4.Replacement and Adjustment Laser Unit To avoid eye injury, turn off the main power switch and unplug the printer before beginning any of the procedures in this section. Caution Decal Locations • The laser can cause serious eye injury. • Be sure to turn off the main power switch and disconnect the power plug from the power outlet before beginning any disassembly or adjustment of the laser unit.
Page 65 4.Replacement and Adjustment Disconnect the three connectors on the EGB. Printer model: MF model: Open the top cover. Remove the harness guide [A] on the left, rear frame. Lift up the hook of the harness guide, and then slide the harness guide to the right.
Page 66 4.Replacement and Adjustment Remove the stoppers [A] and the springs [B] on the left side and right side. Remove the laser unit [A] from the top cover and place it on the main body. To avoid dropping the laser unit, always use two hands to carry it. Release the clamp.
Page 67 4.Replacement and Adjustment Remove the laser unit [A]. After Replacing the Laser Unit After replacing the laser unit, you must enter the LD parameters and adjust color registration. Open the front cover. Turn on the machine. Make sure the machine is in "READY" status. Enter the SP mode.
Page 68: Aio (All In One) Cartridge
4.Replacement and Adjustment AIO (All In One) Cartridge AIO Cartridge Open the top cover. Hold the handle and pull out the AIO cartridge [A]. Black Drum Motor (M2) Remove the left cover. (Left Cover) Disconnect the fusing connector [A]. Release the two hooks to remove the fusing relay connector [A].
Page 69 4.Replacement and Adjustment Remove the fusing harness guide [A]. Remove the PSU cooling fan assembly [A]. Release all harnesses and hook on the harness guide to remove the lower harness guide [A]. Printer model:...
Page 70 4.Replacement and Adjustment MF model: On the MF model only, remove the interlock switch base. (Interlock Switches (SW1/SW2/SW3)) Release all harnesses on the harness guide to remove the upper harness guide [A]. Printer model: MF model:...
Page 71 4.Replacement and Adjustment Remove the drive unit [A]. 10. Release each snap ring and remove the black AIO gear [A], yellow AIO gear [B], and cyan AIO gear [C]. 11. Remove the drive unit guide [A].
Page 72: Color Drum Motor (M1)
4.Replacement and Adjustment 12. Release the snap ring and remove other black AIO gear [B]. 13. Remove the black drum motor (M2) [A]. Color Drum Motor (M1) Remove the left cover. (Left Cover) Remove the drive unit [A] according to Step 2 to 11 in "Black Drum Motor (M2)".
Page 73 4.Replacement and Adjustment gear [C]. Remove the drive unit guide [A]. Release the snap ring and remove the idler gear [B] and magenta AIO gear [C]. Remove the color drum motor (M1) [A].
Page 74: Image Transfer
4.Replacement and Adjustment Image Transfer Waste Toner Bottle Remove all the AIO cartridges. (AIO Cartridge) Remove the paper transfer unit. (Paper Transfer Unit) Pull out the waste toner bottle [A]. Image Transfer Belt Unit Remove all the AIO cartridges (AIO Cartridge).
Page 75 4.Replacement and Adjustment Move the guide plate [C] underneath the fusing unit to the left, and then remove it. Pull out the image transfer belt unit [D]. ( × 2) After Replacing the Image Transfer Belt Unit After replacing the image transfer belt unit, reset the PM counter and execute MUSIC. Open the front cover.
Page 76: Itb Cleaning Unit
4.Replacement and Adjustment ITB Cleaning Unit The ITB cleaning unit contains waste toner. When removing the ITB cleaning unit, put it on a sheet of paper. Remove the image transfer belt unit. (Image Transfer Belt Unit) Release each hook and bushing and remove the left handle [A] and right handle [B]. Remove the ITB cleaning unit [C].
Page 77: Itb Contact Motor (M6)
4.Replacement and Adjustment Remove the motor bracket [A]. ( × 2) Remove the waste toner collection motor assembly [A]. ( × 1, × 1) Remove the waste toner collection motor (M7) [C]. ( × 2) ITB Contact Motor (M6) Remove the rear cover. (Rear Cover)
Page 78 4.Replacement and Adjustment Remove the operation panel. (Operation Panel) Remove the right cover. (Right Cover) Remove the motor bracket [A]. ( × 2) Release the wire [B] and remove the ITB contact motor assembly [C]. ( × 1, × 1) Remove the ITB contact motor (M6) [D].
Page 79: Itb Contact Sensor (S6)
4.Replacement and Adjustment ITB Contact Sensor (S6) Remove the rear cover. (Rear Cover) Remove the operation panel. (Operation Panel) Remove the right cover. (Right Cover) Remove the HVPS. (HVPS (High Voltage Power Supply) (PCB3)) Remove the ITB contact sensor assembly [A]. ( ×...
Page 80 4.Replacement and Adjustment MF model: Disconnect CN306 on the EGB. Remove the harness guide [A] on the left, rear frame. Lift up the hook of the harness guide, and then slide the harness guide to the right.
Page 81: Waste Toner Overflow Sensor (S9)
4.Replacement and Adjustment Remove the TM/P sensor (S8) unit [A]. Waste Toner Overflow Sensor (S9) Remove all AIO cartridges. (AIO Cartridge) Pull out the image transfer belt unit a little. (Image Transfer Belt Unit) Remove the rear cover. (Rear Cover) Remove the controller box cover [A].
Page 82 4.Replacement and Adjustment Remove the AC detection board with the harness guide. (AC Detection Board (PCB5)) Disconnect CN315 on the EGB and remove the two screws fixing the waste toner sensor base. Remove the waste toner sensor base [A].
Page 83: Waste Toner Bottle Set Sensor (S10)
4.Replacement and Adjustment Remove the waste toner overflow sensor (S9) [A]. ( × 1) Waste Toner Bottle Set Sensor (S10) Remove all AIO cartridges. (AIO Cartridge) Pull out the image transfer belt unit a little. (Image Transfer Belt Unit) Remove the rear cover. (Rear Cover) Remove the controller box cover [A].
Page 84 4.Replacement and Adjustment Disconnect CN315 on the EGB and remove two screws fixed the waste toner sensor base. Remove the waste toner sensor base [A]. Remove the waste toner bottle set sensor (S10) [C]. ( × 1)
Page 85: Image Fusing
4.Replacement and Adjustment Image Fusing Make sure that the fusing unit is cool before you touch it. The fusing unit can be very hot. Fusing Unit Remove the left cover. (Left Cover) Disconnect the two connectors. Remove the fusing unit [A]. 保存...
Page 86: Fusing Upper Cover
4.Replacement and Adjustment Enter the SP mode. Execute [Reset Fuser Unit]. Printer model: Engine Maintenance > Reset Fuser MF model: Engine Service Setting > Reset Fuser Unit Fusing Upper Cover Remove the fusing unit. (Fusing Unit) Remove the upper cover [A]. When removing the upper cover, raise up the pressure release levers on both sides.
Page 87: Fusing Entrance Sensor (S2)
4.Replacement and Adjustment Release the hook and slide the entrance guide plate [A] to the right to remove it. Remove the lower cover [A]. Fusing Entrance Sensor (S2) Remove the fusing unit. (Fusing Unit) Remove the fusing lower cover. (Fusing Lower Cover) Remove the fusing entrance sensor assembly, and then remove the fusing entrance sensor (S2) [A].
Page 88: Fusing Nc Sensor (S1)
4.Replacement and Adjustment Remove the fusing upper cover. (Fusing Upper Cover) Remove the fusing thermostat (TH1) [A]. Fusing NC Sensor (S1) Remove the fusing unit. (Fusing Unit) Remove the fusing upper cover. (Fusing Upper Cover) Remove the fusing NC sensor (S1) [A]. Pressure Roller Thermistor (End) (TH4) Remove the fusing unit.
Page 89 4.Replacement and Adjustment Remove the two springs on the fusing exit guide plate [A]. Open the fusing exit guide plate [A] to remove it. Remove the stay [A]. Remove the pressure roller thermistor assembly, and then remove the pressure roller thermistor...
Page 90: Pressure Roller Thermistor (Center) (Th3)
4.Replacement and Adjustment (end) (TH4) [A]. Pressure Roller Thermistor (Center) (TH3) Remove the fusing unit. (Fusing Unit) Remove the fusing upper cover. (Fusing Upper Cover) Remove the fusing lower cover. (Fusing Lower Cover) Remove the two springs on the fusing exit guide plate [A].
Page 91: Fusing Sleeve Belt Unit
4.Replacement and Adjustment Open the fusing exit guide plate [A] to remove it. Remove the stay [A]. Remove the pressure roller thermistor assembly, and then remove the pressure roller thermistor (center) (TH3) [A]. Fusing Sleeve Belt Unit Fusing sleeve belt unit will be available as a service parts around Nov 2019.
Page 92 4.Replacement and Adjustment Remove the fusing unit. (Fusing Unit) Remove the fusing upper cover. (Fusing Upper Cover) Remove the fusing lower cover. (Fusing Lower Cover) Remove the separation pawl [A]. Open the fusing exit guide plate [A]. Remove the two springs [A] on both sides.
Page 93 4.Replacement and Adjustment Open the separation plate [A] to remove it. Release the harness [A] and remove the harness guide [B]. Remove the stay [A].
Page 94: Pressure Roller
4.Replacement and Adjustment 10. Remove the fusing sleeve belt unit [A]. Pressure Roller Remove the fusing unit. (Fusing Unit) Remove the fusing upper cover. (Fusing Upper Cover) Remove the fusing lower cover. (Fusing Lower Cover) Remove the fusing sleeve belt unit. (Fusing Sleeve Belt Unit) Remove the gear cover [A].
Page 95: Fusing Thermopile (Th2)
4.Replacement and Adjustment Remove the e-rings, gear [A], and bearings on both ends, and then remove the pressure roller [B]. Fusing Thermopile (TH2) Remove the fusing unit. (Fusing Unit) Remove the fusing thermopile assembly [A]. Remove the fusing thermopile (TH2) [A].
Page 96: Paper Feed And Transfer
4.Replacement and Adjustment Paper Feed and Transfer Paper Transfer Unit Open the front cover. Pull the levers [A] on both sides to release the lock. Hold the handles on both sides of the paper transfer unit [A] and lift it up and out. 保存...
Page 97: Transfer Roller
4.Replacement and Adjustment Transfer Roller Remove the paper transfer unit. (Paper Transfer Unit) Release the hooks on both ends of the paper transfer unit [A]. Open the transfer roller unit [A] and remove it. Remove the guide plate [A].
Page 98: Registration Roller
4.Replacement and Adjustment Unhook the holder [A] at the left side. Slide the paper transfer roller [B] to the right to remove it. After you install a new paper transfer roller alone, reset the PM counter. See "After Replacing the Paper Transfer Unit".
Page 99: Paper Feed Clutch (Cl1)
4.Replacement and Adjustment onto the bushing of the registration idle roller as shown below. • If the paper dust has accumulated under the registration roller, clean with a soft damp cloth, and then wipe with a dry cloth. Paper Feed Clutch (CL1) Remove the left cover.
Page 100: Fusing Motor (M4)
4.Replacement and Adjustment Remove the paper transport motor (M3) [A]. Fusing Motor (M4) Remove the left cover. (Left Cover) Disconnect the fusing connector [A]. Release two hooks to remove the fusing relay connector [A].
Page 101 4.Replacement and Adjustment Remove the fusing harness guide [A]. Remove the belt cover [A]. Remove the gear [A] with a flat-head screwdriver, and then remove the timing belt [B].
Page 102 4.Replacement and Adjustment Remove the PSU cooling fan with the bracket [A]. Release all harnesses and hook on the harness guide to remove the lower harness guide [A]. Printer model: MF model: On the MF model only, remove the interlock switch base. (Interlock Switches (SW1/SW2/SW3)) 10.
Page 103 4.Replacement and Adjustment MF model: 11. Remove the fusing/transport drive unit [A].
Page 104 4.Replacement and Adjustment 12. Remove the paper transport assembly [A]. 13. Remove the fusing motor assembly [A]. The left screw fastens with the grounding plate [B]. 14. Remove the two gears [A] [B].
Page 105: Registration Clutch (Cl2)
4.Replacement and Adjustment 15. Remove the fusing motor (M4) [A]. Registration Clutch (CL2) Remove the left cover. (Left Cover) Remove the fusing motor. (Fusing Motor (M4)) Remove the registration clutch (CL2) [A]. Paper Feed Roller Remove all AIO cartridges. (AIO Cartridge) Remove the waste toner bottle.
Page 106: Separation Pad
4.Replacement and Adjustment Stand the machine up as shown below. Slide the paper feed shaft [A] to the left side to remove the snap ring on both ends. ( × 2) Release the hook and slide the paper feed roller [B] to remove it. Separation Pad Pull out the paper tray.
Page 107: Paper Exit Roller
4.Replacement and Adjustment Insert a flat-head screwdriver to remove the separation pad [B]. When reinstalling the separation pad, make sure that the film sheet [A] is up as shown and not under the separation pad. Paper Exit Roller Remove the operation panel. (Operation Panel) Remove the bearing [A] and slide the bearing [B] slightly.
Page 108: Paper Exit Sensor (S5)
4.Replacement and Adjustment then remove it. Remove the gear [A], bearing [B] and four exit guides [C]. Paper Exit Sensor (S5) Remove the rear cover. (Rear Cover) Remove the operation panel. (Operation Panel) Remove the right cover. (Right Cover) Remove the bracket [A].
Page 109: Paper End Sensor (S3)
4.Replacement and Adjustment Remove the stopper seal on the back of the paper exit sensor (S5) [A], and then remove the sensor. The stopper seal must be reused, so work carefully to avoid bending or breaking the seal when you remove it.
Page 110: Registration Sensor (S4)
4.Replacement and Adjustment Remove the paper end sensor (S3) [B]. Registration Sensor (S4) Remove the rear cover. (Rear Cover) Remove the operation panel. (Operation Panel) Remove the right cover. (Right Cover) Remove the registration sensor assembly [A] ( × 1, ×...
Page 111 4.Replacement and Adjustment Disconnect the fusing connector [A]. Release the two hooks to remove the fusing relay connector [A]. Remove the fusing harness guide [A]. Remove the interlock switch base. (Interlock Switches (SW1/SW2/SW3)) Release all harnesses on the harness guide to remove the upper harness guide [A]. Printer model:...
Page 112 4.Replacement and Adjustment MF model: Remove the belt cover [A].
Page 113 4.Replacement and Adjustment Remove the gear [A] with a flat-head screwdriver, and then remove the timing belt [B]. 10. Disconnect the two connectors. 11. Remove the bracket [A].
Page 114 4.Replacement and Adjustment 12. On the MF model only, remove the FFC harness guide [A]. 13. Remove the duplex motor (M5) [A].
Page 115: Electrical Components
4.Replacement and Adjustment Electrical Components FCU (PCB8) (MF Model Only) Remove the rear cover. (Rear Cover) Remove the controller box cover [A]. Remove the USB dongle [A] and the interface cover [B]. Remove the FCU (PCB8) [A].
Page 116: Speaker (Mf Model Only)
4.Replacement and Adjustment Speaker (MF Model Only) Remove the rear cover. (Rear Cover) Remove the controller box cover [A]. Remove the speaker assembly [A]. Remove the speaker [A]. Engine Board (EGB) (PCB1) Remove the rear cover. (Rear Cover) Remove the controller box cover [A]. Printer model:...
Page 117 4.Replacement and Adjustment MF model: On the MF model only, remove the USB dongle [A] and interface cover [B].
Page 118 4.Replacement and Adjustment On the MF model only, remove the left stand cover [A]. On the MF model only, disconnect the three FFCs and pull out from the ferrite core [A]. On the MF model only, remove the FCU assembly [A].
Page 119: Eeprom On The Egb
4.Replacement and Adjustment Disconnect all connectors on the EGB (PCB1) [A], and then slide it to remove it. • When installing the new EGB, first remove the EEPROM [A] from the old EGB. Next, install it on the new EGB with the indent pointing to the right side of the board as shown below.
Page 120 Printer model: Engine Maintenance > PnP Name • MF model: Engine Service Setting > PnP Name Enter the appropriate Plug & Play name according to the model: • P C300W: 0x00 • P C301W: 0x03 • M C250FWB: 0x08 •...
Page 121: Controller Board (Pcb2)
4.Replacement and Adjustment • Printer model: Engine Maintenance > Fuser SC Detect • MF model: Engine Service Setting > Fuser SC Detect The default setting is "OFF". Select "ON" only if the customer wants to use this feature. 19. Adjust the registration for each direction (vertical and horizontal directions) and tray if necessary. •...
Page 122: Ac Detection Board (Pcb5)
4.Replacement and Adjustment On the printer model only, remove the USB dongle [A] and the interface cover [B]. Remove the controller board (PCB2) [A]. Printer model: MF model: When disconnecting the FFC, press the button to release the lock. AC Detection Board (PCB5) Remove the rear cover.
Page 123 4.Replacement and Adjustment MF model: On the MF model only, remove the USB dongle [A] and interface cover [B].
Page 124 4.Replacement and Adjustment On the MF model only, remove the left stand cover [A]. On the MF model only, disconnect the three FFCs, and then pull out from the ferrite core [A]. On the MF model only, remove the FCU assembly [A].
Page 125: Hvps (High Voltage Power Supply) (Pcb3)
4.Replacement and Adjustment Release all harnesses and FFC on the harness guide [A], and then remove the guide. Remove the AC detection board (PCB5) [A]. HVPS (High Voltage Power Supply) (PCB3) Remove the rear cover. (Rear Cover) Remove the operation panel. (Operation Panel) Remove the right cover.
Page 126: Temperature/Humidity Sensor (S7)
4.Replacement and Adjustment Temperature/Humidity Sensor (S7) Remove the rear cover. (Rear Cover) Remove the operation panel. (Operation Panel) Remove the right cover. (Right Cover) Remove the temperature/humidity sensor (S7) [A]. Fusing Thermopile Anti-condensation Fan (FAN4) Remove the rear cover. (Rear Cover) Remove the operation panel.
Page 127: Fusing Fan (Fan2)
4.Replacement and Adjustment Remove the interlock switch 2 (SW2) [C] and interlock switch 3 (SW3) [D] at the outside of the base, and then remove the interlock switch 1 (SW1) [E] at the inside of the base. Fusing Fan (FAN2) Remove the left cover.
Page 128: Lsu Fan (Fan1)
4.Replacement and Adjustment Remove the fusing fan (FAN2) [A]. Install the fusing fan with its decal facing out from the machine. LSU Fan (FAN1) Remove the left cover. (Left Cover) Remove the LSU fan (FAN1) [A]. Install the LSU fan with its decal facing out from the machine. PSU Cooling Fan (FAN3) Remove the left cover.
Page 129: Id Chip Board (Pcb6)
4.Replacement and Adjustment Remove the PSU cooling fan (FAN3) [A]. ID Chip Board (PCB6) Remove the rear cover. (Rear Cover) Remove the controller box cover [A]. Printer model: MF model: Remove the left cover. (Left Cover)
Page 130 4.Replacement and Adjustment Disconnect the fusing connector [A]. Release the two hooks to remove the fusing relay connector [A]. Remove the fusing harness guide [A].
Page 131 4.Replacement and Adjustment Remove the PSU cooling fan assembly [A]. Release all harnesses and hook on the harness guide to remove the lower harness guide [A]. Printer model: MF model: Remove the interlock switch base. (Interlock Switches (SW1/SW2/SW3)) 10. Release all harnesses on the harness guide to remove the upper harness guide [A]. Printer model:...
Page 132 4.Replacement and Adjustment MF model: 11. Disconnect the CN100 on the EGB and release the harness [A]. 12. Remove the LSU fan base [B].
Page 133: Psu (Pcb4)
4.Replacement and Adjustment 13. Remove the ID chip board (PCB6) [A]. PSU (PCB4) • Turn off the main power switch and unplug the power cord before replacing the PSU. • To avoid electric shock from residual charge on the board, never touch the areas outlined in red [A] in the following diagrams when replacing the PSU.
Page 134 4.Replacement and Adjustment Disconnect the fusing connector [A]. Release the two hooks to remove the fusing relay connector [A]. Remove the fusing harness guide [A].
Page 135 4.Replacement and Adjustment Remove the PSU cooling fan assembly [A]. Release all harnesses and hook on the harness guide, and then remove the lower harness guide [A]. Printer model: MF model:...
Page 136 4.Replacement and Adjustment Remove the cord bracket [A]. Remove the power switch bracket [A]. 10. Remove the PSU assembly [A].
Page 137: Opu (Pcb7)
4.Replacement and Adjustment 11. Remove the PSU (PCB4) [A]. OPU (PCB7) Printer Model Remove the operation panel. (Operation Panel) Remove the rear cover [A]. Remove the OPU (PCB7) [A]. When disconnecting the FFC, flip up the lock tab to release. MF Model Remove the operation panel.
Page 138 4.Replacement and Adjustment Remove the rear cover [A]. Remove the OPU (PCB7) [A]. The left screw fastens with the grounding plate [B]. When disconnecting the FFC, flip up the lock tab to release.
Page 139: System Maintenance
5.System Maintenance 5. System Maintenance SP Mode Tables (Printer Model) Overview This machine has a service menu. The service menu has several adjustment items. This section explains what you can do in each service menu. Service menu Description Maintenance Display Info Displays the machine information.
Page 140: Engine Maintenance
Engine Maintenance Menu Description PnP Name Sets the Plug and Play name. • P C300W: 0x00 • P C301W: 0x03 [0x00 to 0x7F / - / -] Brand ID Displays the current brand ID number. Do not change this setting (DFU:...
Page 141 5.System Maintenance Menu Description [-5 to 5 / 0 / 0.1mm/step] Vert.Tray2 Adjusts the vertical registration for tray 2. [0 to 5 / 0 / 0.1mm/step] Horiz Bypass Tray Adjusts the horizontal registration for the bypass tray. [-5 to 5 / 0 / 0.1mm/step] Vert Bypass Tray Adjusts the vertical registration for the bypass tray.
Page 142 5.System Maintenance Menu Description • Cardstock • Envelope • Thick Paper 1 • Thick Paper 2 2nd Front Adjusts the transfer roller current (front side), based on the default value. [-15 to 15 / 0 / 1µA/step] 2nd Back Adjusts the transfer roller current (back side), based on the default value.
Page 143 5.System Maintenance Menu Description This calibrates the motor speed to match the length of the new transfer belt. Fuser SC Fus. Jam Dete. Determines whether or not the SC code Detect is issued after three successive jams in the fusing unit. [0 (OFF) or 1(ON)] SC Number Displays the SC number occurred.
Page 144 5.System Maintenance Menu Description temperature detected error (hardware) occurred. Color Registration Executes the MUSIC. Special Mode (DFU) Init LSU Data Resets the LD driver parameters written to the EEPROM on the EGB. Fuser Unit Fus. Temp. Dly Heat Center Displays the current temperature (°C) at the fusing thermopile.
Page 145 5.System Maintenance Menu Description • MiddleThick:BW Thick1 • Thick1:FC Thick2 • Postcard Thick1:BW • Envelope Thick2:FC • Label Thick2:BW Postcard:FC Postcard:BW Envelope:FC Envelope:BW Label:FC Label:BW Curl Correction Execute Pattern Selects paper curl correction setting. [0 (OFF) / 1 (All Modes) / 2 (Execute for Paper Type, Thickness)] Humi.:Thres:M- Display and set humidity threshold...
Page 146 5.System Maintenance Menu Description • Plain2:BW Plain1 • MiddleThick:FC Plain2 • Middle Thick MiddleThick:BW • Thick1 Thick1:FC • Thick2 Thick1:BW • Postcard Thick2:FC • Envelope Thick2:BW • Label Postcard:FC Postcard:BW Envelope:FC Envelope:BW Label:FC Label:BW Band Check Executes measurement of the nip bandwidth.
Page 147 5.System Maintenance Menu Description Previous 2:Pages Displays page count (sheets) for the 2nd fusing unit before current unit. Previous Displays distance count (mm) for the 2nd 2:Distance fusing unit before current unit. Previous 3:Pages Displays page count (sheets) for the 3rd fusing unit before current unit.
Page 148 5.System Maintenance Menu Description Sensor 0: Paper present, 1: No paper Paper End Displays the paper end sensor status. Detection 0: Paper present, 1: No paper Exit Sensor Displays the paper exit sensor status. 0: Paper present, 1: No paper Fusing Entrance Displays the fusing entrance sensor Sensor...
Page 149 5.System Maintenance Menu Description Inter. Rel. Displays the interlock 2 status. Detect./2 0: Door open, 1: Door closed Fault Detection Displays the failure status in order of R8C, registration clutch, paper feed clutch, bank feed clutch, bank transport clutch, duplex motor. 0: Abnormal, 1: Normal OUTPUT Check ITB Contact...
Page 150 5.System Maintenance Menu Description Bank: Transport Turns the bank transport clutch on. Fusing Cond Fan Operates the fusing thermopile anti- condensation fan. MUSIC For. Posit. Adj. mode.a Executes the line position adjustment (Mode a: Normal process control). mode.b Executes the line position adjustment (Mode b: Toner coverage process control).
Page 151 5.System Maintenance Menu Description light emitted from left TM/P sensor after Vsg adjustment succeeded. Reserve TrgtAdhnsnAmt:Set [0.10 to 7.5 / 4.78 / 0.01g/m ImageRetry Function Sets for Image Retry Function. [0 (Disable) / 1 (Enable)] ReserveUW1 Reserved ReserveUW2 Reserved PM Parts Notice Sets whether to display the PM parts replacement notice and whether to stop the engine.
Page 152: Factory Default
5.System Maintenance Factory Default Menu Description Factory Return Resets all the settings to factory default. Default Clears/ resets the contents of the controller memory (all data programmed by the user, log data application counters) to factory default. After executing, initial setup menu starts after power-on. Execute Does not execute anything.
Page 153: Remote
5.System Maintenance Menu Description • 0: None • 1: Vertical line (1 dot) • 2: Horizontal line (1 dot) • 3: Vertical line (2 dots) • 4: Horizontal line (2 dots) • 5: Grid vertical line • 6: Grid horizontal line •...
Page 154 5.System Maintenance Menu Description [Disable/ Enable] Comm. Test Call Sets the communication test call. [Disable/ Enable] Machine Info Notice Sets the machine information notice. [Disable/ Enable] Supply Auto Sets the supply auto ordering call. Ordering Call [Disable/ Enable] Machine No. ID2 Code Display Displays the ID2 code (ASCII 17digits).
Page 155 5.System Maintenance Menu Description Cnt Notice Mode Sets the counter notification mode. [0 to 5 / 0 / 1/step] Per Notice Time Displays the periodic notification date and time. Cnt Notice Time Displays the counter notification date and time. Cnt End Time Displays the counter closing date and time.
Page 156 5.System Maintenance Menu Description CountNotify Week Displays periodic notification timing (day of the week). Reg. Notify Int. Displays the counter notification timing (interval). Reg. Notify Week Displays the counter notification timing (day of the week). SSL Port Specifies the SSL communication port. [0 to 65535 / 443 / 1/step] Poling Man Exc Executes poling.
Page 157: Sp Mode Tables (Mf Model)
5.System Maintenance SP Mode Tables (MF Model) Overview This machine has a service menu. The service menu has several adjustment items. This section explains what you can do in each service menu. Service menu Description SP Menu Information Display Displays the machine information. (Information Display) Print Report...
Page 158: Prints Report
5.System Maintenance Menu Description Color Image Displays the number of sheets scanned in color. ADF/DADF Displays the number of sheets scanned using ADF. Used Jam Counter Jam Total Displays the total number of paper jams. ADF/DADF Displays the number of paper jams in the ADF. Printer Out Displays the number of paper jams in the output tray.
Page 159 5.System Maintenance Menu Description Maintenance ID Displays the current maintenance ID number. Do not change this setting (DFU). [0x00 to 0x7F / - / -] 2nd Transfer Media Type Selects the media type in order to set the paper transfer current. “2nd Front”...
Page 160 5.System Maintenance Menu Description Graphic Determines the maximum amount of toner you can use in any area of your graphic. [Off, 200 to 400 / 250 / 10/step] Image Determines the maximum amount of toner you can use in any area of your image.
Page 161 5.System Maintenance Menu Description the EEPROM on the EGB. Init. LSU data Resets the LD driver parameters written to the EEPROM on the EGB. Trans. Belt Adjustment Executes the transfer belt adjustment. This calibrates the motor speed to match the length of the new transfer belt.
Page 162 5.System Maintenance Menu Description Press Left current SC code. Press Right Temp.before 2cycles Heat Center Displays the temperature (°C) of Heat NC each sensor at the occurrence of the 2nd fusing SC code before the Press Center current SC code. Press Left Press Right Temp.before 3cycles...
Page 163 5.System Maintenance Menu Description end: Notice “Replace Now” • 3: At near end: Notice, At life end: Notice “Replace Now” and stopped Fuser Unit Fusing Temp. Heat Center Displays the current temperature Display (°C) at the fusing thermopile. Heat NC Displays the current temperature (°C) at the fusing NC sensor.
Page 164 5.System Maintenance Menu Description • MiddleThick:FC Middle Thick • MiddleThick:BW Thick1 • Thick2 Thick1:FC • Postcard Thick1:BW • Envelope Thick2:FC • Label Thick2:BW Postcard:FC Postcard:BW Envelope:FC Envelope:BW Label:FC Label:BW Curl Correction 1 Execute Pattern Selects paper curl correction setting. [0 (OFF) / 1 (All Modes) / 2 (Execute for Paper Type, Thickness)] Humidity:Threshold:M-...
Page 165 5.System Maintenance Menu Description Correction:speed3 Thin:BW ON/OFF for Line Speed 3 for each paper type and printing mode. Plain1:FC [0 (OFF) / 1(ON)] Plain1:BW • Thin Plain2:FC • Plain1 Plain2:BW • Plain2 MiddleThick:FC • Middle Thick MiddleThick:BW • Thick1 Thick1:FC •...
Page 166 5.System Maintenance Menu Description Current:Distance Displays current distance count (mm) for the fusing unit. Previous 1:Pages Displays page count (sheets) for the 1st unit before current fusing unit. Previous 1:Distance Displays distance count (mm) for the 1st unit before current fusing unit.
Page 167 5.System Maintenance Menu Description voltage. Displays min. value of detected voltage. Last Displays the value of most recently detected voltage. Displays the detected voltage at time of SC occurrence. Threshold Voltage Displays detected voltage at STOP. Inrush Control Sets the Inrush Control mode. When using with an external power supply instead of a commercial power supply, set to "On".
Page 168 5.System Maintenance Menu Description 0: Set, 1: Not set Bank:Paper End Displays the bank paper end Detection sensor status. 0: Paper present, 1: No paper Bank:Set Sensor Displays the bank set status. 0: Set, 1: Not set Bank:Transport Sensor Displays the bank transport sensor status.
Page 169 5.System Maintenance Menu Description Transf. Drum Mot. K: Stand. Duplex:CW: Middle Rotates the duplex motor forward. Duplex:CW: Standard Duplex:CCW: Low Rotates the duplex motor in Speed reverse. Duplex:CCW: Middle Feed Motor FC: Rotates the paper transport motor. CCW:Low Note: This cannot be used if the jam is Feed Motor FC: CCW: remaining in the machine except Stand.
Page 170 5.System Maintenance Menu Description Result Displays result of MUSIC execution. (1: Success) Displays result of MUSIC execution (times executed). Failure Displays result of MUSIC execution (times failed). Error C Displays result of MUSIC execution (C errors). Error M Displays result of MUSIC execution (M errors).
Page 171: Scanner Service Setting
5.System Maintenance Scanner Service Setting Menu Description Mono Compression Sets the monochrome compression type for scanning. [MH (Default)/ MR/ MMR] Registration Adjust ADF Main Reg. Adjusts the ADF main-scan registration. [-1.0 to 1.5 / 0 / 0.1mm/step] ADF Sub Reg. Adjusts the ADF sub-scan registration.
Page 172: Fax Service Setting
5.System Maintenance Menu Description Dark Backside CIS- Blue- [-10 to 10 / 0 / 1/step] Dark Backside CIS- Gray- [-10 to 10 / 0 / 1/step] Dark Copy Original Edge Flatbed Top Adjusts the leading-edge margin for flatbed mask scanning. [-3.0 to 3.0 / 0 / 0.1mm/step] Flatbed Bottom Adjusts the trailing-edge margin for flatbed...
Page 173 5.System Maintenance Menu Description [0Km/ 1.8Km/ 3.6Km/ 7.2Km] Protocol Training Retries This sets the number of training retries to be repeated Definition before automatic fallback. [1 Time / 2 Times / 3 Times / 4 Times] Encoding Sets the compression method for Tx/Rx. [MMR+MR+MH / MR+MH / MH] Protocol T0 Timer...
Page 174 5.System Maintenance Menu Description Number of time to [1 to 3 / 2 / 1step] press Period for TEL to FAX [Limitless / 10 sec / 20 sec/ 30 sec/ 40 sec] TX Settings Redial Interval Sets the redial interval when Tx fails. [5 Min / 6 Min] Redialings Sets the number of redials when Tx fails.
Page 175 5.System Maintenance Menu Description 1Dial Tone Wait Time The machine starts dialing after the specified interval Detection without detection of a dial tone when Dial tone detection is set to "No detection". [3.5 Sec / 7.0 Sec / 10.5 Sec / 14.0 Sec] Timeout Length This setting sets the time-out length for the 1st dial tone detection.
Page 176: Ctl Sp
5.System Maintenance Menu Description 28800 Bps / 31200 Bps / 33600 Bps] Symbol Rate This setting limits the transmission speed range in V.34 mode by masking the desired symbol rate(s). [Not Used / 3429 Sym/Sec / 3200 Sym/Sec / 3000 Sym/Sec / 2800 Sym/Sec / 2400 Sym/Sec] Internet Fax Disable/Enable Sets whether the Internet Fax function is used or not.
Page 177: Test Pattern
5.System Maintenance Menu [Off / On] Sleep Mode Setting [Off / On] Test Pattern Menu Description Test Pattern Pattern Selection Selects the test pattern. [0 to 23 / 0 / 1/step] • 0: None • 1: Vertical line (1 dot) •...
Page 178: Remote
5.System Maintenance @Remote Menu Description Supply Alarm Toner Sets the toner supply alarm. [Disable / Enable] Toner Call Timing [At rplcment / At NearEnd] SC/Alarm SC Call Sets the SC call. Setting [Disable / Enable] User Call Sets the user call. [Disable / Enable] Comm.
Page 179 5.System Maintenance Menu Description HTTP Con Delay Specifies the connection request sending delay. [0 to 255 / 5 / 1 sec/step] Max Multipart Specifies the maximum number of multipart. [0 to 10 / 10 / 1/step] Rescue G/W URL Displays the rescue URL. Per Notice Mode Sets the periodic notification mode.
Page 180 5.System Maintenance Menu Description Svr CNCheck Sets the server authentication CN check. [Disable / Enable] CERT:GW URL Displays the NRS Gateway URL. CERT:Use Pass Displays the availability of PassPhrase. CERT:Use MAC Displays the availability of MAC. CountNotify Int. Display periodic notification timing (interval). CountNotify Week Displays periodic notification timing (day of the week).
Page 181: Calibrating The Lcd (Mf Model Only)
5.System Maintenance Calibrating the LCD (MF Model Only) You can calibrate the touch screen with the LCD Coordinate Maintenance Mode. For further information, contact the supervisor in your branch office. 1.Set operation panel Set the calibration coordinates for the touch panel. coordinate 2.Check operation panel Check the position of the coordinates for the touch panel with the 5...
Page 182 5.System Maintenance Press [OK[#]] on the screen (or press [#] on the number keys) to save. Press [2.Check operation panel coordinate] (or press the [2] key on the number keys). Tap 9 black (+) marks displayed on the screen, and then check that the position of the coordinates is within an acceptable range.
Page 183 5.System Maintenance Press [OK[#]] on the screen (or press [#] on the number keys) to exit.
Page 184: Fax Service Test Menu (Mf Model Only)
5.System Maintenance Fax Service Test Menu (MF Model Only) Entering the Fax Service Test Menu For further information, contact the supervisor in your branch office. Selecting an Item Select the item which you want to execute. Exiting the Fax Service Test Menu Press [Exit].
Page 185: Print List/Report
5.System Maintenance Print List/Report Types of Lists/Reports Report name Description Configuration Page Prints general information and the current configurations of the machine. Fax Journal (MF model only) Prints a fax transmission and reception journal for the last 50 jobs. TX/RX Standby Files (MF Prints a list of fax jobs remaining in the machine's memory to be model only) printed, sent, or forwarded.
Page 186: Report Examples
5.System Maintenance Press [Yes]. The report is printed. Press [Exit] to return to the previous menu. Report Examples Configuration Page For details, refer to "Configuration Page". Fax Journal TX/RX Standby Files Quick Dial Dest.
Page 187 5.System Maintenance Fax Speed Dial Dest. Scanner Dest. List Scanner Journal Maintenance Page For details, refer to "Maintenance Report".
Page 188 5.System Maintenance Special Sender List Configuration Page Printer model...
Page 189 5.System Maintenance MF model...
Page 190 5.System Maintenance The following contents can be confirmed in the configuration page. Category Description System Reference Displays the model name, machine ID, and firmware version. paper Input Displays the paper size and type settings. Supplies Status Displays consumable usage on a scale. Counter Displays various types of counters.
Page 191 5.System Maintenance MF model The following contents can be confirmed in the Maintenance Report.
Page 192: Test Page
5.System Maintenance Item Description System settings Displays the model name, machine ID, and firmware version. Paper settings Displays the paper size and type settings. Supplies status Displays consumable usage on a scale. QR code The printer IP address is converted to a QR code and displayed. If the Wi-Fi Direct function is enabled, it displays the Wi-Fi Direct IP address, otherwise it displays the Wi-Fi or Ethernet IP address.
Page 193 5.System Maintenance For Printer Model Press the [Menu] key. Press the [ ] or [ ] key to select [Printer Features], and then press the [OK] key. Press the [ ] or [ ] key to select [List/Test Print], and then press the [OK] key. Press the [ ] or [ ] key to select [Test page], and then press the [OK] key.
Page 194: Firmware Updating
5.System Maintenance Firmware Updating • Do not turn off the main power of the machine during the firmware updating. If doing so, the engine board or controller board may be damaged. • Never disconnect the cable you are using for the updates during the update process. •...
Page 195: Updating The Controller Firmware
5.System Maintenance Updating the Controller Firmware • Do not operate the machine using the operation panel, access the machine using Web Image Monitor, perform fax transmissions, printing, or TWAIN scanning during the update process. • The update may take a while to complete. Do not turn off the power during the update. Turn off the power only when an update completion message appears on the machine's operation panel.
Page 196 5.System Maintenance Read the cautionary statements carefully, and then click [OK]. The firmware update tool opens. For a USB connection, click "Firmware Update (USB)" [A]. For a network connection, enter the machine's IP address in "Machine IP address" [B], and then click "Firmware Update (LAN)"...
Page 197 5.System Maintenance Printer model: MF model: Wait until the update completion message appears on the machine’s operation panel. Printer model: MF model:...
Page 198: Updating The Engine Firmware
5.System Maintenance Click “Close” [A] to close the update tool. The machine restarts following a firmware update. 10. Wait until the Home screen or "Ready" appears on the machine's operation panel. 11. Print a configuration or maintenance page to check the machine's firmware version. 12.
Page 199 5.System Maintenance Monitor, perform fax transmissions, printing, or TWAIN scanning during the update process. • The update may take a while to complete. Do not turn off the power during the update. Turn off the power only when an update completion message appears on the machine's operation panel.
Page 200 5.System Maintenance For a USB connection, click [Eng. F/W Update (USB)]. For a network connection, enter the machine's IP address in [Machine IP address], and then click [Eng. F/W Update (LAN)]. Do not use the [F/W Update (USB)] and [F/W Update (LAN)]. The firmware update starts.
Page 201 5.System Maintenance 10. Click [Close] to close the update tool. 11. Close the top cover. 12. Turn off the power of the machine, and then turn it back on. 13. Print a configuration or maintenance page to check the machine's firmware version. •...
Page 202: Capturing The Debug Logs
5.System Maintenance Capturing the Debug Logs Overview You can use the Web Image Monitor to get debug logs. Retrieving the Debug Logs A PC is necessary to acquire the debug log. Enter the following URL in the browser: http://<ip address>/Primax-debug-info.asp?en-us After going to the "Webpage Debug Page", select the following items one at a time.
Page 203 5.System Maintenance Item name Description be selected. Offset and Size should be smaller than the total engine flash memory size. Get Debug Get the debug log data from the log buffer. Message The log buffer is set to 3000 lines by default for MF models and 2000 lines by default for P models.
Page 204: Troubleshooting
6.Troubleshooting 6. Troubleshooting Service Call Service Call Conditions The ‘SC Table’ section shows the SC codes for controller errors and other errors. The latter are put into four types. The type is determined by their reset procedures. The table shows the classification of the SC codes.
Page 205: Sc 2Xx (Image Writing)
6.Troubleshooting SC No. Type Error Name/Error Condition/Major Cause/Solution The product identification code in the machine serial number (11 digits) does not match. Turn the power OFF then ON. Check the serial number. SC 2xx (Image Writing) SC No. Type Error Name/Error Condition/Major Cause/Solution SC202- Polygon mirror motor: ON timeout error After the polygon mirror motor turned on, or within the specified time (sec.) after...
Page 206 6.Troubleshooting SC No. Type Error Name/Error Condition/Major Cause/Solution Check if the SC occurs by turning the power OFF then ON. If the SC occurs again, do the following steps. Check if the SC reoccurs by cycling the power after each step.
Page 207 6.Troubleshooting SC No. Type Error Name/Error Condition/Major Cause/Solution • EGB (PCB1) defective • Harness between the synchronization detection board and LDB. Check if the SC occurs by turning the power OFF then ON. If the SC occurs again, do the following steps. Check if the SC reoccurs by cycling the power after each step.
Page 208: Sc 3Xx (Around The Drum)
6.Troubleshooting SC No. Type Error Name/Error Condition/Major Cause/Solution The power supply for the LDB is abnormal during the startup operation of the machine or after the cover is closed. • EGB (PCB1) defective (LD +5VS power error) • LDB defective (LD driver defective) •...
Page 209: Sc 4Xx (Image Transfer)
6.Troubleshooting SC No. Type Error Name/Error Condition/Major Cause/Solution • EGB (PCB1) defective • AIO (C, M, or Y) overload Check if the SC occurs by turning the power OFF then ON. If the SC occurs again, do the following steps. Check if the SC reoccurs by cycling the power after each step.
Page 210 6.Troubleshooting SC No. Type Error Name/Error Condition/Major Cause/Solution SC442- ITB (Image transfer belt): Home position shift abnormality The ITB contact sensor does not detect the home position of the ITB within 3 seconds after the ITB contact motor is turned ON. SC442- ITB (Image transfer belt): Contact position shift abnormality The ITB contact sensor does not detect the contact position of the ITB within 3...
Page 211 6.Troubleshooting SC No. Type Error Name/Error Condition/Major Cause/Solution Replace the ITB unit. Reconnect the connectors. Replace the ITB contact sensor (S6). Replace the ITB contact motor (M6). Replace the TM/P sensor (S8). Replace the EGB (PCB1). SC No. Type Error Name/Error Condition/Major Cause/Solution SC491- High voltage power: Charge/development/transfer bias output error An error signal was detected continuously for 200 msec during charge bias,...
Page 212: Sc 5Xx ( Paper Feed And Fusing)
6.Troubleshooting SC No. Type Error Name/Error Condition/Major Cause/Solution Reconnect the CN800 connector on the HVPS (PCB3). Re-install the HVPS (PCB3). Replace the HVPS (PCB3). Replace the EGB (PCB1). 10. Replace the harnesses on the HVPS (PCB3). SC No. Type Error Name/Error Condition/Major Cause/Solution SC495- Waste toner collection motor (M7) error The waste toner collection motor error is detected more than 3 times when the...
Page 213 6.Troubleshooting SC No. Type Error Name/Error Condition/Major Cause/Solution SC530- LSU fan (FAN1) error (operating) A motor malfunction was detected because the lock signal remained HIGH (motor not rotating normally) 50 consecutive times when checked at 100 ms intervals after the motor switched ON. SC530- LSU fan (FAN1) error (at rest) A motor malfunction was detected because the lock signal detected LOW 70...
Page 214 6.Troubleshooting SC No. Type Error Name/Error Condition/Major Cause/Solution Replace the EGB (PCB1). SC No. Type Error Name/Error Condition/Major Cause/Solution SC532- Fusing fan (FAN2) error (operating) A motor malfunction was detected because the lock signal remained HIGH (motor not rotating normally) 50 consecutive times when checked at 100 ms intervals after the motor switched ON.
Page 215 6.Troubleshooting SC No. Type Error Name/Error Condition/Major Cause/Solution Replace the fusing thermopile anti-condensation fan (FAN4). Re-connect the connector of the fusing thermopile anti-condensation fan (FAN4). Replace the fusing thermopile anti-condensation fan (FAN4) harness. Replace the EGB (PCB1). SC No. Type Error Name/Error Condition/Major Cause/Solution SC541- Fusing thermopile (TH2) disconnect error...
Page 216 6.Troubleshooting SC No. Type Error Name/Error Condition/Major Cause/Solution Replace the fusing thermostat (TH1). SC No. Type Error Name/Error Condition/Major Cause/Solution SC542- No reload temperature of the fusing thermopile (TH2): Low voltage After turning the fusing lamp on, the fusing thermopile has failed to reach the reload temperature (96 °C) continuously for 8.6 seconds.
Page 217 6.Troubleshooting SC No. Type Error Name/Error Condition/Major Cause/Solution SC544- High-temperature hardware error (fusing thermopile (TH2)) After the initial setting is completed at startup or returning from energy saver mode, the fusing thermopile has detected over 250 °C continuously for 0.03 seconds. •...
Page 218 6.Troubleshooting SC No. Type Error Name/Error Condition/Major Cause/Solution • Overheating protection device triggered (blown fusing thermostat) Check if the SC occurs by turning the power OFF then ON. If the SC occurs again, do the following steps. Check if the SC reoccurs by cycling the power after each step.
Page 219 6.Troubleshooting SC No. Type Error Name/Error Condition/Major Cause/Solution SC547- Zero cross-error (relay contact error) Zero cross processing executed for 0.5 seconds, but relay shut OFF/ON when zero cross was not generated even once. The process is done three times. • Damaged fusion relay (contact open) •...
Page 220 6.Troubleshooting SC No. Type Error Name/Error Condition/Major Cause/Solution Measurement is started 60 seconds after turning the fusing lamp ON, and the fusing thermopile (TH2) has detected -100 °C from the target temperature continuously for 60 seconds. AND the power supply voltage is lower than specified voltage.
Page 221 6.Troubleshooting SC No. Type Error Name/Error Condition/Major Cause/Solution • Fusing NC sensor disconnected • Harness connector lose, broken, or defective Enter the SP mode and execute fuser SC reset. Then turn the machine OFF and If the SC occurs again, do the following steps. Check if the SC reoccurs by cycling the power after each step.
Page 222 6.Troubleshooting SC No. Type Error Name/Error Condition/Major Cause/Solution None SC No. Type Error Name/Error Condition/Major Cause/Solution SC561- Pressure roller thermistor (center) (TH3) disconnect error After turning the fusing lamp ON, the pressure roller thermistor (center) has detected -20 °C or less continuously for 28 seconds. •...
Page 223 6.Troubleshooting SC No. Type Error Name/Error Condition/Major Cause/Solution • Thermistor is deformed or not in contact • Power supply voltage low • Overheating protection device triggered (blown fusing thermostat) • Fusing drive non-rotation Enter the SP mode and execute fuser SC reset. Then turn the machine OFF and If the SC occurs again, do the following steps.
Page 224 6.Troubleshooting SC No. Type Error Name/Error Condition/Major Cause/Solution • TRIAC short • EGB (PCB1) defective • Pressure roller thermistor (center) (TH3) defective Enter the SP mode and execute fuser SC reset. Then turn the machine OFF and If the SC occurs again, do the following steps. Check if the SC reoccurs by cycling the power after each step.
Page 225 6.Troubleshooting SC No. Type Error Name/Error Condition/Major Cause/Solution the power after each step. Re-connect the connector of the pressure roller thermistor (end) (TH4) harness. Replace the pressure roller thermistor (end) (TH4). SC No. Type Error Name/Error Condition/Major Cause/Solution SC571- Pressure roller thermistor (end) (TH4) disconnect error: Low voltage After turning the fusing lamp ON, the pressure roller thermistor (end) has detected -20 °C or less continuously for 28 seconds.
Page 226 6.Troubleshooting SC No. Type Error Name/Error Condition/Major Cause/Solution Replace the fusing unit. Replace the EGB (PCB1) or/and the PSU (PCB4). SC No. Type Error Name/Error Condition/Major Cause/Solution SC572- No reload temperature of the pressure roller thermistor (end) (TH4): Low voltage After turning the fusing lamp ON, the pressure roller thermistor (end) has failed to reach -40 °C continuously for 30 seconds.
Page 227: Sc 6Xx (Device Communication)
6.Troubleshooting SC No. Type Error Name/Error Condition/Major Cause/Solution SC574- High-temperature hardware error (pressure roller thermistor (end) (TH4)) After the initial setting is completed at startup or returning from energy saver mode, the pressure roller thermistor (end) has detected over 240 °C continuously for 0.03 seconds.
Page 228 6.Troubleshooting SC No. Type Error Name/Error Condition/Major Cause/Solution SC645- ID chip connection error (C) SC645- ID chip connection error (Y) An error is notified during EEPROM communication and the machine does not recover after two retries. ID chip connection failure Check if the SC occurs by turning the power OFF then ON.
Page 229 6.Troubleshooting SC No. Type Error Name/Error Condition/Major Cause/Solution SC669- EEPROM communication error: Communication timeout error SC669- EEPROM communication error: Not operating error during EEPROM OPEN SC669- EEPROM communication error: Buffer full during EEPROM OPEN SC669- EEPROM communication error: No error code during EEPROM OPEN SC669- EEPROM communication error: ID error during EEPROM CLOSE SC669-...
Page 230 6.Troubleshooting SC No. Type Error Name/Error Condition/Major Cause/Solution SC669- EEPROM communication error: Not operating error during EEPROM data read SC669- EEPROM communication error: Buffer full during EEPROM data read SC669- EEPROM communication error: No error code during EEPROM data read SC669- EEPROM communication error: Verification error SC669-...
Page 231 6.Troubleshooting SC No. Type Error Name/Error Condition/Major Cause/Solution SC681- Channel error (C) SC681- Channel error (Y) SC681- Device error (K) SC681- Device error (M) SC681- Device error (C) SC681- Device error (Y) SC681- Communication error (K) SC681- Communication error (M) SC681- Communication error (C) SC681-...
Page 232: Sc 9Xx (Other Error)
6.Troubleshooting SC No. Type Error Name/Error Condition/Major Cause/Solution SC681- The requested buffer is full (M) SC681- The requested buffer is full (C) SC681- The requested buffer is full (Y) SC681- Verification error (K) SC681- Verification error (M) SC681- Verification error (C) SC681- Verification error (Y) An error is notified during the ID identification after three retries.
Page 233 6.Troubleshooting SC No. Type Error Name/Error Condition/Major Cause/Solution SC detection due to hardware specifications. Check if the SC occurs by turning the power OFF then ON. If the SC occurs again, do the following steps. Check if the SC reoccurs by cycling the power after each step.
Page 234: Fax Error Code (Mf Model Only)
6.Troubleshooting Fax Error Code (MF Model Only) This error code definition is for dial errors, TX communication errors, and RX communication errors. The error code is printed on the TX Report/Activity Report/G3 Protocol dump list. Fax Error Code Structure Error codes consist of six hexadecimal digits (0-5). Digit 5 (far left) TX or RX 1xxxxx...
Page 235: Fax Error Code Table
6.Troubleshooting Digit 2 Modem speed xxxaxx 24000 xxxbxx 26400 xxxcxx 28800 xxxdxx 31200 xxxexx 33600 Fax Error Code Table Error Error Type Error Description Code General Normal (No Error) xxxx01 STOP xxxx1f H/W Error 1xxx11 Scanner Error during TX 2xxx14 Memory Full during RX xxxx06 Authorized Reception = Enable,...
Page 236 6.Troubleshooting Error Error Type Error Description Code xxxx53 JBIG Buffer Full xxxx60 Comm. Error Retry Out Phase-D Error xxxx61 T2 Time Out xxxx62 DCN received xxxx63 Too many CRPs xxxx64 Too many PPRs xxxx65 RNR Time Out xxxx66 RTN/PIN Received, EOR/ERR/DCN xxxx67 Invalid Command/Response RX...
Page 237: Jam Detection
6.Troubleshooting Jam Detection Jam Detection Jam Message List Here is a list of common jam messages, and descriptions of the causes. Main machine Jam message Jam type Cause Misfeed: XXX Initial jam Paper stays at any sensor. Misfeed: Tray 1 Tray 1 misfeed Paper does not reach the registration sensor.
Page 238: Transport Path Length
6.Troubleshooting ADF (Only MF model) Transport Path Length Main machine Transport path Length (mm) Note Paper feed roller - Registration sensor ON 49.1...
Page 239 6.Troubleshooting Transport path Length (mm) Note Paper feed roller - Friction pad nip Registration sensor ON - Registration sensor OFF Registration sensor ON - Registration roller 14.3 Registration roller - Paper transfer roller 38.1 Paper transfer roller - Fusing entrance sensor ON 60.7 Fusing entrance sensor ON - Fusing entrance sensor OFF Paper transfer roller - Fusing sleeve belt...
Page 240: Paper Delivery Problems
6.Troubleshooting Paper Delivery Problems Image Has Shifted Out of Position Problem Cause Details Solution Double colors Poor positioning caused by Can occur at the To correct out of position (colors out of the change in temperature beginning of colors: position) in text or during printing.
Page 241 6.Troubleshooting Problem Cause Details Solution • Paper jams A paper jam has not Paper in poor Change how the paper is set occur been removed, or condition. by rotating the stack front-to- frequently paper in poor back end, front-to-back side. •...
Page 242: Poor Paper Feed
6.Troubleshooting Poor Paper Feed Problem Cause Details Solution • Paper not Paper set If the paper is thick and Check installation of the paper feeding incorrectly has been left unwrapped tray. • correctly Paper in poor for a long time, or it is Remove the stack and fan it to condition recycled paper, replace...
Page 243: Bypass Paper Skew
6.Troubleshooting Problem Cause Details Solution overloaded. correctly in its vinyl packs until ready for use. • Explain that paper should not be stacked higher than the load limit mark. Bypass Paper Skew • The quality of paper feed from the bypass tray (rate of skew and other problems) is beyond the scope of quality assurance.
Page 244 6.Troubleshooting Bypass Tray”. • After setting the paper tray completely against the back, the machine will automatically feed the paper about 12 mm. • Always set the paper for short-edge feed (SEF) with the print side down. • Paper cannot be fed from the bypass tray for duplex printing. •...
Page 245: Image Quality Problems
6.Troubleshooting Image Quality Problems Vertical Streaking Problem Cause Details Solution • Vertical, fine black ITB cleaning blade has Dust and dirt in the Clean the area around the lines appear. become contaminated environment. machine. • After the lines first with toner, dust, due to a Discontinue use of Replace the paper in use.
Page 246 6.Troubleshooting Problem Cause Details Solution toner from the surface of the OPC or the ITB. • • Vertical, fine white Dust, dirt caught on Can occur at the Remove and reinstall the lines appear the doctor blade is beginning of AIO.
Page 247: Horizontal Lines
6.Troubleshooting Horizontal Lines Problem Cause Details Solution Color streaks occur There is a problem with Can occur at the Replace the AIO. horizontally at 27 mm the development roller. beginning of machine intervals. use or over time. Fine horizontal lines appear. There is a problem with The problem presents Check the ITB or...
Page 248: Spotted Images
6.Troubleshooting Problem Cause Details Solution occur at use or over time. regular • 76 mm OPC drum may have Leave the AIO in AIO was intervals intervals been accidentally replaced while the machine and exposed to ambient light. machine was wait for the accidentally problem to...
Page 249: Uneven Color
6.Troubleshooting Problem Cause Details Solution images the development unit is operating in high the machine. dropping onto paper ambient If occurrence is (paper path timing). temperature and frequent, replace • Something has humidity. the AIO. jammed into the OPC The problem seal, allowing waste presents over time.
Page 250 6.Troubleshooting Problem Cause Details Solution appear at 27 mm correctly. of machine use or over the AIO. (or 81 mm) time. intervals Note: 81 mm = 27 mm × 3 pitch White spots There is a problem with The problem presents over Check the ITB or appear at 25 mm the image transfer unit.
Page 251: Other Causes Of Dirty Copies
6.Troubleshooting Problem Cause Details Solution Registration Other Causes of Dirty Copies Problem Cause Details Solution • Dirty backs of The paper transfer roller The paper transfer roller printed sheets and pressure roller can get is self-cleaning so the dirty when servicing jams. fouling should not continue.
Page 252: Problem At Regular Intervals
6.Troubleshooting Problem Cause Details Solution Offset image. Printing on thick paper in Check conditions in the Image peels Plain Paper mode. paper path. because toner not fused to paper. Problem at Regular Intervals Image problems may appear at regular intervals that depend on the circumference of certain components The following diagram shows the possible symptoms (black or white dots at regular intervals).
Page 253: Irregular, Uneven Coverage
6.Troubleshooting Irregular, Uneven Coverage The quality of the image transfer can degrade, depending on the status of the machine (paper humidity control or paper type) or season and installation environment (HH environment / LL environment, etc.). Solution Adjust the bias current of the paper transfer roller. The current bias setting for the paper transfer roller can be adjusted for paper (media) type in the SP mode.
Page 254 6.Troubleshooting Solution Always avoid touching the surface of the image transfer belt when servicing or replacing the image transfer unit.
Page 255: Other Information
6.Troubleshooting Other Information Spurious Noise Problem Cause Details Solution A spurious A blockage in the AIO Can occur at the beginning Remove and squeaking noise is waste toner path is of machine use. reinstall the AIO. heard at 0.3 sec. causing the toner coil to If this does not intervals...
Page 256 6.Troubleshooting The information is display from the top in the order K > M > C > Y. 15 items can be checked for each color. Parameter Details Item Data type Range/Default/Step Details Comments Bk rate 2byte(HEX) 0.0 to 100.0 / 0 / Displays BW print If AIO in use is 0.1%/step...
Page 257 6.Troubleshooting Item Data type Range/Default/Step Details Comments count (lower 10 time/step MUSIC bits) executions Unit output sheet 4byte(HEX) 0 to 4294967595 / 0 K denotes total Jams are not count / 1 sheet/step number of BW included in the and color prints, counts.
Page 258: Machine Operation With Toner Level Alert
6.Troubleshooting Error code Description FFF0 For AIO in use, cannot be calculated. FFF1 Number of machine prints is “0”, cannot be calculated. FFF2 Number of BW/Color prints for AIO in use is "0", cannot be calculated. FFF3 Calculation for Bk rate exceeds upper or lower limit. FFF4 Division by "0"...
Page 259: Curl Preventive Mode Precautions
6.Troubleshooting Print rate Print condition (P/J) Number of sheets printed (K sheets) 11.1 Curl Preventive Mode Precautions Selecting "Curl Preventive Mode" from the menu and switching ON suppresses paper curl. • Printer model: Menu key > System Settings > Curl Preventive Mode •...
Page 260 6.Troubleshooting Flowchart...
Page 261: Detailed Descriptions
7.Detailed Descriptions 7. Detailed Descriptions Guidance for Those Who are Familiar with Predecessor Products Function Previous C260 series New (This model) Printer model MF model Printer MF model model C260DNw/C262DN C260SFNw/C262SF C300W/301 350FWB/250F Operation panel Two–line LCD 4.3 inch touch panel Four–line 4.3 inch touch panel...
Page 262 7.Detailed Descriptions Function Previous C260 series New (This model) Printer model MF model Printer MF model model C260DNw/C262DN C260SFNw/C262SF C300W/301 350FWB/250F condensation around the thermopile. Wireless LAN Wi-fi board USB dongle (5GHz band supported) @Remote Not Supported Supported...
Page 263: Machine Overview
7.Detailed Descriptions Machine Overview Component Layout Laser unit Print cartridge (AIO) Development roller (AIO) Paper exit Fusing unit Fusing lamp Paper transfer roller Registration roller Bypass tray 10. Paper feed roller 11. OPC (AIO) 12. ITB (Image transfer belt) unit 13.
Page 264: Paper Path
7.Detailed Descriptions Paper Path Main machine paper feed path (Tray 1) Duplex paper feed path Bypass paper feed path Optional tray paper feed path (Tray 2) Drive Layout Color drum motor (M1) Black drum motor (M2)
Page 265: Electrical Component
7.Detailed Descriptions Duplex motor (M5) Fusing motor (M4) Paper transport motor (M3) Registration clutch (CL2) Paper feed clutch (CL1) ITB contact motor (M6) Waste toner collection motor (M7) Electrical Component ADF Unit (Only MF Model) Name Name ADF pick-up roller ADF motor (M8) ADF feed roller Back registration sensor (S13)
Page 266 7.Detailed Descriptions Scanner Unit (Only MF Model) Name Name CIS carriage unit Scanner HP sensor (S14) Carriage drive shaft Scanner motor (M9) Scanner timing belt Laser Exposure Unit, Motors Name Name LDB (C/M) Paper transport motor (M3) LDB (K/Y) Fusing motor (M4) Synchronizing detector board Registration clutch (CL2) Polygon mirror motor...
Page 267 7.Detailed Descriptions Name Name Waste toner collection motor (M7) Color drum motor (M1) Duplex motor (M5) TM/P sensor (S8) Sensors Name Name Paper exit sensor (S5) Waste toner bottle set sensor (S10) Registration sensor (S4) ITB contact sensor (S6) Paper end sensor (S3) Fusing entrance sensor (S2) Waste toner overflow sensor (S9)
Page 268 7.Detailed Descriptions Fusing Unit, ID Chip Name Name Fusing lamp (H1) Pressure roller thermistor (end) (TH4) Pressure roller thermistor (center) (TH3) ID chip (K) Fusing NC sensor (S1) ID chip (Y) Fusing thermopile (TH2) *At main machine side ID chip (M) Fusing thermostat (TH1) ID chip (C) Boards...
Page 269 7.Detailed Descriptions Name Name OPU (PCB7) FCU (PCB8) *Only MF model EGB (Engine board) (PCB1) Controller board (PCB2) Speaker *Only MF model Fans, Boards, Switches Name Name Temperature/humidity sensor (S7) PSU cooling fan (FAN3) HVPS (PCB3) LSU fan (FAN1) Fusing thermopile anti-condensation fan (FAN4) AC detection board (PCB5) ID chip board (PCB6) Interlock switch 3 (SW3)
Page 270: Adf (Mf Model Only)
7.Detailed Descriptions ADF (MF Model Only) Overview Part name Part name ADF pick-up roller Original set sensor (S11) Original set sensor feeler Original exit roller ADF feed roller ADF exposure glass *At scanner unit side ADF separation pad Back ADF exposure glass Transport roller Back CIS Back registration sensor (S13)
Page 271 7.Detailed Descriptions...
Page 272: Scanner (Mf Model Only)
7.Detailed Descriptions Scanner (MF Model Only) Overview Part name DF exposure glass White sheet *At ADF unit side CIS carriage unit Scanner exposure glass Carriage drive shaft Mechanism The scanner motor [A] drives the CIS carriage unit [B] through gears and a timing belt [C]. The CIS carriage unit moves along the carriage drive shaft [D].
Page 273: Laser Exposure
7.Detailed Descriptions Laser Exposure Overview Part name LDB (C/M) Lens Polygon mirror motor Synchronizing detector board LDB (K/Y) Mechanism Composition This machine uses two LDB units and one polygon mirror motor [A] to produce latent images on four OPC drums [B] (one drum for each color toner). There are two hexagonal mirrors.
Page 274 7.Detailed Descriptions LD Safety Switch A safety switch stops the machine operation when the front cover or the top cover is opened. As a result, the relay on the PSU cuts off the power supply (+5V) to the two LD boards. (The circuits go through the EGB.) This system prevents unexpected laser emission, and ensures user safety and technician safety.
Page 275: Music (Mirror Unit Skew And Interval Correction)
7.Detailed Descriptions MUSIC (Mirror Unit Skew and Interval Correction) During MUSIC, the line patterns above are made 16 times for fine adjustment or 8 times for the rough adjustment on the transfer belt. The spaces between the lines (YY, KK, CC, MM, KY, KC, KM) are measured by the front, center, and rear TM/P sensors.
Page 276: Aio Cartridge
7.Detailed Descriptions AIO Cartridge Overview This machine uses the AIO (All In One) system. Each AIO consists of the waste toner tank, print cartridge part, development unit part, and OPC part. This gives the user easy replacement procedures and helps to make the engine module more compact. The waste toner bottle is smaller than other full- color printers because the waste toner from the OPC is collected in the waste toner tank of each AIO.
Page 277: Mechanism
7.Detailed Descriptions Mechanism Drive The black drum motor [A] drives the gear for the black AIO. The color drum motor [B] drives the color gears for the cyan, magenta and yellow AIOs through gears. Each of these gears engages with a gear [C] in the OPC, and this gear drives the rollers in the AIO through other gears.
Page 278 7.Detailed Descriptions OPC Charge and Cleaning This machine uses a charge roller [A]. The charge roller gives the drum surface a negative charge. The high voltage supply board, which is at the left side of the machine, applies a dc and ac voltage (at a constant current) to the roller. The ac voltage helps to make sure that the charge given to the drum is as constant as possible.
Page 279 7.Detailed Descriptions toner up to the waste toner container [E]. The collected waste toner is moved to the left side of the AIO by the waste toner collection coil [D]. A flexible sheet [F] separates the unused toner area from the waste toner area. The waste toner area becomes larger when toner is consumed.
Page 280 7.Detailed Descriptions Development This machine does not use developer, so a TD sensor is not necessary. In each AIO unit, the toner supply roller [A] supplies toner to the development roller [B]. Electrostatic attraction generated by the friction between the toner supply roller and development roller moves toner to the surface of the development roller, and the development blade [C] makes sure that the layer of toner on the development roller has an even thickness.
Page 281: Process Control
7.Detailed Descriptions Process Control Process Control Flow Process control adjusts imaging processing conditions as required to maintain constant, uniform image density. Process control comprises toner coverage control and MUSIC (Mirror Unit Skew and Interval Correction) which ensures consistent color overlay. Toner Coverage Control The machine uses the temperature and humidity readings of the temperature/humidity sensor to determine the correct bias for the application of charge to the surface of the drum to ensure that...
Page 282: Process Control Timing And Triggers
7.Detailed Descriptions Three TM/P sensors monitor color offset in the main scan and sub scan directions at each point [A] (left), [B] (center), and [C] (right). They measure and calculate the amount main scan shift and magnification errors, as well as sub scan shift skew and bending. The center TM/P sensor is also used to detect the amount of toner coverage in the patterns on the drum for toner coverage process control.
Page 283 7.Detailed Descriptions Process Control Process Control Triggers Control Action Timing Front or top cover At paper jam No action is closed When changes in ambient conditions are detected Toner coverage control, and MUSIC execute Other than above MUSIC executes Standby mode When changes in ambient conditions are detected Toner coverage control, and MUSIC execute...
Page 284: Image Transfer
7.Detailed Descriptions Image Transfer Overview The transfer unit is composed of four components of the image transfer belt unit, the ITB cleaning unit, the paper transfer unit, and the waste toner bottle. Part name Image transfer belt unit ITB (image transfer belt) cleaning unit Paper transfer unit Waste toner bottle Mechanism...
Page 285 7.Detailed Descriptions The black drum motor [A] controls the transfer belt drive roller [B]. The belt tension roller adds tension to the transfer belt to help to turn this belt. The image transfer belt rollers [C] are charged from terminal plates to move the toner from the OPCs to the image transfer belt.
Page 286 7.Detailed Descriptions ITB Cleaning Unit The ITB cleaning blade [A] in the cleaning unit removes remaining toner on the image transfer belt after image transfer to the paper. The toner collection coil [B] moves the collected waste toner to the outlet for the waste toner bottle.
Page 287 7.Detailed Descriptions The transfer roller [A] is always pressed against the image transfer belt by pressure from a spring. The transfer roller moves toner images [B] from the transfer belt to the paper. When a sheet of paper [C] goes between the transfer roller and the transfer belt, the transfer roller turns with the paper. The transfer unit has a discharge plate [D] above the transfer roller.
Page 288: Image Fusing
7.Detailed Descriptions Image Fusing Overview Part name Part name Pressure roller Fusing thermostat (TH1) Pressure roller thermistor (center/ end) Fusing thermopile (TH2) *At main (TH3/TH4) machine side Fusing entrance sensor (S2) Fusing NC sensor (S1) Fusing lamp (H1) Separation plate Fusing sleeve belt Mechanism Fusing Mechanism...
Page 289 7.Detailed Descriptions The heat from the fusing lamp [A] is reflected by the reflector [B] and heats the fusing sleeve belt [C]. The nip pad [D] at the sleeve belt side is pushed against the pressure roller [E] and keeps the nip width on the sleeve belt.
Page 290 7.Detailed Descriptions shutdown, replace the fusing unit with a new unit. SC No. SC name Monitored location Conditions SC543- Fusing thermopile high temperature detected Fusing sleeve belt 240°C (Software) (center) surface SC544- Fusing thermopile high temperature detected Fusing sleeve belt 250 to (Hardware) (center) surface...
Page 291 7.Detailed Descriptions Item Target temperature (Plain paper 1) Reload Temperature 168°C Standby Temperature 60°C Ready Temperature 126°C Post Paper-Feed Temperature 150°C CPM Down Control This machine employs several CPM down modes to maintain the quality of printed images and to optimize and protect the operation of the machine.
Page 292: Paper Feed
7.Detailed Descriptions Paper Feed Overview Part name Part name Paper feed roller Paper height lever Registration sensor feeler Separation pad Registration roller Paper end sensor (S3) This machine has a paper tray (250 sheets) and a bypass paper feed (single sheet). The paper feed mechanism uses a friction pad system.
Page 293 7.Detailed Descriptions The paper feed roller feeds a sheet of paper to the registration roller. When the registration sensor [F] detects a sheet of paper, the machine makes a paper buckle at the registration roller to correct paper skew. After that, the registration clutch turns on, and then the registration roller transports a sheet of paper to the transfer roller unit.
Page 294 7.Detailed Descriptions while a sheet of paper is set in the bypass tray, an initial jam occurs. When manual feed printing continuously, set the second sheet after the first sheet is printed.
Page 295: Paper Exit And Duplex
7.Detailed Descriptions Paper Exit and Duplex Overview Part name Paper exit roller Duplex motor (M5) Paper exit sensor feeler Paper exit sensor (S5)
Page 296: Mechanism
7.Detailed Descriptions Mechanism Drive The duplex motor [B] feeds out paper to the output tray in single-sided mode and also feeds paper to the duplex path in duplex mode. When a sheet of paper is detected by the paper exit sensor [C] in duplex mode, the duplex motor stops and rotates in reverse.
Page 297: Boards
7.Detailed Descriptions Boards Block Diagram Printer Model...
Page 298: Board Outline
7.Detailed Descriptions MF Model Board Outline EGB (Engine Board) The engine board controls the following functions: • Engine sequence • Controller interface Controller Board The controller board controls the following functions: • LAN interface (10Base-T/100Base-T) • USB2.0 interface • Operation panel interface...
Page 299 7.Detailed Descriptions • Wi-fi module interface PSU (Power Supply Unit) The PSU converts AC mains to DC and supplies power to the machine. HVPS (High-Voltage Power Supply) The HVPS controls the high-voltage power required for process control. AC Detection Board The AC detection board detects the voltage of the mains AC supply.
Page 300 P C300W/C301W, M C250FWB/C250FW Machine Code: M0CS/M0CW/M0CX/M0CZ Appendices Ver 1.0 Latest Release: July, 2019 Initial Release: July, 2019 (c) 2019 Ricoh Co.,Ltd.
Page 302 Table of Contents Specifications ............................ 2 General Specifications .......................... 2 Printer Model ............................ 2 MF Model ............................4 Supported Paper Size/Type ........................9 Optional Equipment ..........................11 Paper Feed Unit TK1220 ........................ 11 Preventive Maintenance ......................... 12 Maintenance Table ..........................12 FAQs/Knowledge Base ........................
Page 303: Specifications
1.Specifications 1. Specifications General Specifications Printer Model General Function Item Description Configuration Desktop Print process Laser electrostatic transfer Maximum paper size for printing Legal Warm-up time (23 °C, 71.6 °F) 20 seconds or less Paper sizes Tray 1, Bypass Tray A4, B5 JIS, A5 LEF, A5 SEF, B6 JIS, A6, 8 x 14, 8 x 11, 5...
Page 304 1.Specifications Item Description ADF capacity (80g/m , 20lb) 50 sheets Memory 256 MB Power 120-127 V, 11 A, 60 Hz requirement EU, Asia, China 220-240 V, 6 A, 50/60 Hz Power Maximum 1300 W or less consumption Ready 30.5 W During Color: 461 W printing...
Page 305: Mf Model
1.Specifications MF Model General Function Item Description Configuration Desktop Print process Laser electrostatic transfer Maximum paper Exposure glass A4, Letter size for scanning Legal Maximum paper size for printing Legal Warm-up time (23 °C, 71.6 °F) 20 seconds or less Paper sizes Tray 1, Bypass Tray A4, B5 JIS, A5 LEF, A5 SEF, B6 JIS, A6, 8...
Page 306 1.Specifications Item Description Power 120-127 V, 11 A, 60 Hz requirement EU, Asia, China 220-240 V, 6 A, 50/60 Hz Power Maximum 1300 W or less consumption Ready 34.5 W During Color: 469 W printing B/W: 428 W EU, Asia, Maximum 1300 W or less China...
Page 307 1.Specifications Item Description Scanning: 300 x 600 dpi Printing: 600 x 600 dpi First copy speed (A4, at 23 °C, 71.6 °F) B/W: 15 seconds or less Color: 19 seconds or less Gradation Scanning: 256 levels Printing: Four-value Multiple Copy When copying multiple simplex originals 25 ppm (A4, Letter) Speed...
Page 308 1.Specifications Item Description Scanning time B/W: 5 seconds or less Color: 10 seconds or less (A4/600 dpi/Compressed) Not including transfer time. ADF throughput B/W: 20 ipm (300 x 600 dpi) Color: 12 ipm (300 x 600 dpi) • Interface Ethernet (10BASE-T, 100BASE-TX) •...
Page 309 1.Specifications Item Description Transmission function E-mail E-mail format Single/Multi-part, MIME Conversion Attached file forms (transmission): TIFF-S (MH encoding) Attached file forms (reception): TIFF-S/TIFF-F (MH/MR/MMR encoding) Authentication method SMTP-AUTH, POP before SMTP, A-POP Original size A4 (Length is up to 356 mm) Resolution 8 dots/mm x 3.85 lines/mm (200 x 100 dpi) 8 dots/mm x 7.7 lines/mm (200 x 200 dpi)
Page 310: Supported Paper Size/Type
1.Specifications Supported Paper Size/Type After loading paper in the tray, specify the paper type and size using the control panel. This machine does not detect the paper size automatically. Need to select paper size with operation panel/driver. Paper Size Supported. Not supported Paper Size inch...
Page 311 1.Specifications Paper Size inch Tray 1 Bypass Tray Duplex Tray 2 (Option) Eng Quatro 8 x 10 Custom Width 90-216 mm (3.54-8.50”) Length 148-356 mm (5.83-14.0”) Paper Type Supported Not supported Type Thickness Tray 1 Bypass Tray Duplex Tray 2 (Option) Thin 60-65 g/m Plain 1...
Page 312: Optional Equipment
1.Specifications Optional Equipment Paper Feed Unit TK1220 Item Description Paper Tray Paper Size A4, Letter (8 x 11 inches) (500 sheets x 1) Paper Weight 60 to 105 g/m (16 to 28 lb.) Paper capacity 500 sheets Dimensions (W x D x H) 400 x 450 x 127 mm (15.8 x 17.8 x 5 inches) Weight Less than 4 kg (8.9 lb.)
Page 313: Preventive Maintenance
2.Preventive Maintenance 2. Preventive Maintenance Maintenance Table Symbol keys: C: Clean, R: Replace (R): Yield Parts The parts mentioned in these tables have a target yield. However, the total copy/print volume made by the machine will not reach the target yield within the machine's targeted lifetime if the machine is used under the target usage conditions (ACV, color ratio, and P/J).
Page 314: Faqs/Knowledge Base
3.FAQs/Knowledge Base 3. FAQs/Knowledge Base You can access the FAQs and knowledge base for this model through Web Image Monitor. http://machine’s_IP_address Click ‘FAQ/Knowledge Base’ at the top right of the screen.
Page 315: Paas Setup Procedure
4.Setting for PaaS (Only for CHN) 4. Setting for PaaS (Only for CHN) PaaS (Printer as a service) is a system that ensures device uptime is maximized through real time monitoring of machine status and proactive handling of maintenance requirements. PaaS Setup Procedure The customer Contract ID and the customer authentication key are required for authentication.
Page 316 4.Setting for PaaS (Only for CHN) registration. Launch the web browser. In the web browser’s address bar, enter http://(machine’s IP address)/ to access the machine. On the Web Image Monitor menu, select [PaaS (Printer as a Service) Settings]. Check that [Operation] is set to "Contract Registration". Operation List: Item Description...
Page 317 4.Setting for PaaS (Only for CHN) Registration Configurations List: Item Description Contract ID Enter the customer Contract ID. Authentication Key Enter the customer Authentication Key. PaaS URL China: rpaasdev.online.tj.cn If noPaaS URL is specified, enter the PaaS URL above. If using a proxy server, enter the proxy information. Proxy Function List: Item Description...
Page 318 4.Setting for PaaS (Only for CHN) PaaS Error Message List: Message Description Registration Configuration is The Contract ID or Authentication Key you have entered is either not correct wrong or already being used. Check that the Contract ID and Authentication Key are correct. Operation failed, please Contact the service center.
Page 319: Unregistering Paas
4.Setting for PaaS (Only for CHN) Unregistering PaaS To unregister, it is necessary to follow the cancellation procedure on the PaaS server side in advance. Launch the web browser. In the web browser’s address bar, enter http://(machine’s IP address)/ to access the machine. On the Web Image Monitor menu, select [PaaS (Printer as a Service) Settings].
Page 320: Changing Registered Device/ Main Board
4.Setting for PaaS (Only for CHN) Changing Registered Device/ Main Board To change the PaaS registered device or if the EGB has been replaced, follow the procedure below on the new device. The existing customer Contract ID and customer authentication key are required for authentication. Note: It is not necessary to obtain a new contract ID and authentication key to change a registered device or EGB.
Page 321 4.Setting for PaaS (Only for CHN) Launch the web browser. In the web browser’s address bar, enter http://(machine’s IP address)/ to access the machine. On the Web Image Monitor menu, select [PaaS (Printer as a Service) Settings]. Check that [Operation] is set to "Device Replacement". Operation List: Item Description...
Page 322 4.Setting for PaaS (Only for CHN) Item Description Contract ID Enter the customer Contract ID. Authentication Key Enter the customer Authentication Key. PaaS URL China: rpaasdev.online.tj.cn If no PaaS URL is specified, enter the PaaS URL above. If using a proxy server, enter the proxy information. Proxy Function List: Item Description...
Page 323 4.Setting for PaaS (Only for CHN) Message Description Registration Configuration is The Contract ID or Authentication Key you have entered is either not correct wrong or already being used. Check that the Contract ID and Authentication Key are correct. Operation failed, please Contact the service center.
Page 324: Technical Tips
4.Setting for PaaS (Only for CHN) Technical Tips • Only execute the “Factory Default” when it is necessary. If the machine is reset by the Factory Default operation, the PaaS settings will be reset and deleted. In the event that the Factory Default is executed, set the PaaS again through the procedure in "Overwrite Registration on Server".
