Mains and Supply Voltage Connection
6.1

Connection Features

• Rexroth EcoDrive Cs drive controllers must be permanently connected
to the power supply network.
• Single-phase and three-phase connection possible
• Mains and supply voltage connection have to be done via individual
cables.
• It is impossible to interconnect the DC buses and group or central
supply is therefore impossible!
• The control voltage (24 V) is generated internally. For control voltage
supply 230 V are connected externally.
• Connection by means of WAGO terminal blocks
