Electrical Connection - REXROTH EcoDrive Cs Project Planning Manual

10-28
Additional Components

Electrical connection

RF interference suppression filter
LINE
L
Q2
N
PE
central
ground
LED green = output
voltage applied
DC 24 V V+
Output
voltage
Zero point V-
Protective ground
Input
voltage
1)
1)
A/B not connected, input voltage AC (170-265) V
A/B connected with bridge, input voltage AC (85-132) V
2)
V+/S+ or V-/S- are connected with bridges
Remove the bridges for using the sensor inputs.
Fig. 10-39: Front view and terminal designation of the power supplies
NTM01.1-024-004 and NTM01.1-024-006
Note: Always
NFE01.1-250-006. For further information on NFE, see project
planning manual "Electromagnetic Compatibility (EMC) in
Drive
DOK-GENERL-EMV********-PRxx.
LOAD
NFE ...
Fig. 10-40: Connecting the power supply to a line filter
Note: The contact bridge between V+/S+ and V-/S- must be
removed if sensor inputs are used.
V+
V-
FG
L
N
use the NTM together
and Control
Power supply
L V+
+DC 24 V
NTM ...
N V-
0 V
DOK-ECODR3-DKC**.3-CS*-PR02-EN-P
Rexroth EcoDrive Cs Drives
Potentiometer for fine
adjustments of output
voltage
2)
S+ sensor input
2)
S- sensor input
Input voltage
A
setting
1)
B
via bridge
FA0200F1.FH7
with the line
Systems", doc.-type
to the control voltage
connection on the
drive controller
AP0202F1.FH7
filter
