Introduction to the System
1.3
Drive Controller – Motor Combinations
Drive controller
DKCxx.x-004
DKCxx.x-008
DKCxx.x-012
DKCxx.x-018
Note:
The individual drive controllers may only be operated with the
respective motors.
Motor
MSM020B-0300-NN-C0-CG0
MSM020B-0300-NN-C0-CG1
MSM020B-0300-NN-C0-CC0
MSM020B-0300-NN-C0-CC1
MSM020B-0300-NN-M0-CG0
MSM020B-0300-NN-M0-CG1
MSM020B-0300-NN-M0-CC0
MSM020B-0300-NN-M0-CC1
MSM030B-0300-NN-C0-CG0
MSM030B-0300-NN-C0-CG1
MSM030B-0300-NN-C0-CC0
MSM030B-0300-NN-C0-CC1
MSM030B-0300-NN-M0-CG0
MSM030B-0300-NN-M0-CG1
MSM030B-0300-NN-M0-CC0
MSM030B-0300-NN-M0-CC1
MSM030C-0300-NN-C0-CG0
MSM030C-0300-NN-C0-CG1
MSM030C-0300-NN-C0-CC0
MSM030C-0300-NN-C0-CC1
MSM030C-0300-NN-M0-CG0
MSM030C-0300-NN-M0-CG1
MSM030C-0300-NN-M0-CC0
MSM030C-0300-NN-M0-CC1
MSM040B-0300-NN-C0-CG0
MSM040B-0300-NN-C0-CG1
MSM040B-0300-NN-C0-CC0
MSM040B-0300-NN-C0-CC1
MSM040B-0300-NN-M0-CG0
MSM040B-0300-NN-M0-CG1
MSM040B-0300-NN-M0-CC0
MSM040B-0300-NN-M0-CC1
Fig. 1-3: Drive controller – motor combinations
Rexroth EcoDrive Cs Drives
Properties (motor)
100 W: incremental, plain shaft, without brake
100 W: incremental, plain shaft, with brake
100 W: incremental, key, without brake
100 W: incremental, key, with brake
100 W: absolute, plain shaft, without brake
100 W: absolute, plain shaft, with brake
100 W: absolute, key, without brake
100 W: absolute, key, with brake
200 W: incremental, plain shaft, without brake
200 W: incremental, plain shaft, with brake
200 W: incremental, key, without brake
200 W: incremental, key, with brake
200 W: absolute, plain shaft, without brake
200 W: absolute, plain shaft, with brake
200 W: absolute, key, without brake
200 W: absolute, key, with brake
400 W: incremental, plain shaft, without brake
400 W: incremental, plain shaft, with brake
400 W: incremental, key, without brake
400 W: incremental, key, with brake
400 W: absolute, plain shaft, without brake
400 W: absolute, plain shaft, with brake
400 W: absolute, key, without brake
400 W: absolute, key, with brake
750 W: incremental, plain shaft, without brake
750 W: incremental, plain shaft, with brake
750 W: incremental, key, without brake
750 W: incremental, key, with brake
750 W: absolute, plain shaft, without brake
750 W: absolute, plain shaft, with brake
750 W: absolute, key, without brake
750 W: absolute, key, with brake
DOK-ECODR3-DKC**.3-CS*-PR02-EN-P
