8-22
Motors

Key

A
25

Cables at the Motor

Motor Cable
Encoder Cable
A
B
B C
22 6h9
all data in mm
Fig. 8-28: Key
1
1: encoder cable
2: motor cable
Fig. 8-29: Cables at the motor
Length of cables (motor ↔ connector):
• motor cable: 200 mm (+70 mm connector)
• encoder cable: 220 mm (+62 mm connector)
See chapter 10.1
See chapter 10.1
Rexroth EcoDrive Cs Drives
C
D
E
passfeder.fh7
D
6
2
motor_kabel_m_g.fh7
DOK-ECODR3-DKC**.3-CS*-PR02-EN-P
E
15.5
