8-4
Motors

Motor MSM040B

Abbrev.
Column
Example:
1. Product
1.1 MSM. . . . . . . . . = MSM
2. Size
2.1 040 . . . . . . . . . . . . . . . . . = 040
3. Length
3.1 Length . . . . . . . . . . . . . . . . . . . . = B
4. Windings
4.1 MSM040B . . . . . . . . . . . . . . . . . . . . . = 0300
5. Cooling mode
5.1 natural convection, without blower . . . . . . . . . . . . = NN
6. Encoder
6.1 Incremental encoder
6.2 Multiturn absolute encoder
7. Electrical connection
7.1 cable tail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . = C
8. Shaft
8.1 key per DIN 6885-1.. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . = C
8.2 plain shaft . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . = G
9. Holding brake
9.1 without holding brake . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . = 0
9.2 electrical release 2.45 Nm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . = 1
10. Standard reference
Standard Title
DIN 6885-1 Drive Type with Fastenings without Taper Action;
Parallel Keys, Keyways, Deep Pattern
1
1 2 3 4 5 6 7 8 9 0 1 2 3 4
M S M 0 4 0 B - 0 3 0 0 - N N - C 0 - C G 1
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . =
. . . . . . . . . . . . . . . . . . . . . . . . . . . .=
Fig. 8-3: Type code for motor MSM040B
Note: If you select a motor, regard the detailed informations in
the descriptions of the motors and the informations in
chapter 8.8 "Application Instructions".
2
5 6 7 8 9 0 1 2 3 4 5 6 7 8 9
C0
M0
Edition
1968-08
DOK-ECODR3-DKC**.3-CS*-PR02-EN-P
Rexroth EcoDrive Cs Drives
3 4
0 1 2 3 4 5 6 7 8 9 0
