5. Connect connector attached to the battery to one of the two mating
connectors on the drive controller
mating connector
connector
6. Attach battery cover. Push cover upwards until it snaps in
7. Dispose old battery according to the valid directions of your country
battery
batteriefach_front.fh7
8-47
