5-32
Electrical Connections
Position of Position of
switch S20/1 switch S20/2
OFF
ON
OFF
ON
Data Rate
Transmission
power with opt.
high level in dBm
OFF -7
OFF -4.5
ON -1
ON 0
Fig. 5-63: Relationship between switch position S20/1, S20/2 and the
transmission power
(*1): The data for the maximum lengths of the fiber optic cables only apply
if the following preconditions have been met:
•
fiber optic cables IKO 982, IKO985 or IKO 001 approved by Rexroth
are used
•
Connection without separating points. If separating points (couplings)
are used, the maximum length for plastic fiber optic cables is reduced
by approx. 10 meters, by approx. 100 meters for glass fiber optic
cables.
The data rate is automatically set by the firmware.
Fiber Optic Cables
Drive controllers with a SERCOS interface are connected to higher-level
control units by means of fiber optic cables.
The fiber optic cables (cable, connector, or the entire ready-made cables)
have to be ordered separately.
For more detailed information on the subject of "fiber optic cables" please
refer to the Application Manual "LWL - Handling" (Fiber Optic Cable
Handling), (DOK-CONNEC-CABLE*LWL**-AWxx-EN-P,
284755).
The following points are dealt with in the "LWL – Handling" (Fiber Optic
Cable Handling) manual:
• general information on fiber optic cables
• basic planning information for optical transmission systems
• instructions for laying fiber optic cables
• attenuation measurement on ready-made fiber optic cable
• available fiber optic FSMA plug-in connectors and fiber optic cables
• instructions for assembling FSMA connectors
• tools for assembling fiber optic cables
Rexroth EcoDrive Cs Drives
Transmission max. length
power with opt. with plastic
high level in µW fiber optic cable
200 0...15 m
350 15...25 m
800 25...35 m
1000 35...50 m
DOK-ECODR3-DKC**.3-CS*-PR02-EN-P
max. length
with glass
fiber optic
cable (*1)
--
--
--
0...500 m
