Encoder Emulation Cable RKG0008
70
white
brown
green
black
DOK-ECODR3-DKC**.3-CS*-PR02-EN-P
order length = length of unfinished cable
RKG0008
gray
pink
blue
red
Fig. 10-5:
Encoder emulation cable
100
RKG0008
drive controller
2
0,14 mm
2
0,14 mm
0,14 mm
2
0,14 mm
2
0,14 mm
2
0,14 mm
2
0,14 mm
2
0,14 mm
2
Additional Components
1
UA1+
2
UA1-
3
GND
4
GND
5
UA2+/CLK+
6
UA2-/CLK-
7
UA0+/Data+
8
UA0-/Data-
