Rexroth EcoDrive Cs Drives

Dimensional sheets and installation dimensions

Front views

DOK-ECODR3-DKC**.3-CS*-PR02-EN-P
A
Power supply
NTM01.1-024-..
A1
D
A
Table of dimensions
INDRAMAT
A
Type of power supply
173
NTM01.1-024-002
NTM01.1-024-004 202
NTM01.1-024-006 212
Fig. 10-37: Dimensional sheet DC24V – NTM power supplies
LED green = output
voltage applied
DC 24 V V+
Output
voltage
Zero point V-
Protective ground FG
Input
voltage
1)
Pins not connected = input voltage AC (200-240) V
Pins connected = input voltage AC (100-120) V
Fig. 10-38: Front view and terminal designations of the power supply
NTM01.1-024-002
Additional Components
B
A1 B C D
168.7 100 45 17
197.7 97 51 20
207.7 97 70 20
L
N
10-27
C
C
C
A Connecting block
B L rails DIN 50
C > 20 mm
cooling clearance
MB0204F1.FH7
Potentiometer for fine
adjustments of output
voltage
Pins for changing input
1)
voltage
FA0201F1.FH7
