Assembly

Skilled Technical Personnel

Mounting the Motor

General for mounting
If the optional holding brake is
Any work on the system and on the drives or in their vicinity may only be
carried out by appropriately trained technical personnel. The owner of the
system must ensure that all persons carrying out
• installation work,
• maintenance measures, or
• operation activities
on the system are adequately familiar with the contents of this
documentation as well as with all warnings and precautionary measures
contained therein. Qualified technical personnel must have been trained
and instructed and are authorized to activate and deactivate, ground and
mark electric circuits and equipment according to the safety rules and
regulations. Qualified technical personnel must possess the appropriate
safety equipment and have been trained in first aid.
Observe all warnings and safety advices mentioned in chapter 3. This
minimizes the risk of accidents and damage to the system or the motor.
Do all handling advices carefully. This ensures correct mounting and
dismounting of the components.
Before mounting:
1. Procure tools, auxiliary materials, measuring and test equipment.
2. Control all components if they are clean.
3. Proof all components if they are obviously damaged. Defective
components may not be mounted.
4. Ensure that mounting can be done in a dry and clean environment.
5. Ensure that the holder for the motor flange is without burrs.
6. Check whether the motor brake attains the braking moment provided
used
in the data sheet. If the brake does not attain the moment provided,
first grind the brake. Then proceed as follows.
