Rexroth EcoDrive Cs Drives
1

Introduction to the System

1.1

Rexroth EcoDrive Cs Drive System

DOK-ECODR3-DKC**.3-CS*-PR02-EN-P
Rexroth EcoDrive Cs is a new generation of system-compatible AC servo
drives in the lower power range of 100 to 750 W. The drive controllers
and motors have a specifically compact design.
The drive controllers are equipped with the SERCOS interface,
PROFIBUS-DP, DeviceNet or CANopen master communication modules;
they are perfectly suited for use in systems with multiple-axis devices and
can also be used as intelligent single axes on a standard field bus.
There are four motor sizes (100 W, 200 W, 400 W, 750 W) with minimum
dimensions that are adapted to the drive controllers.
The following options are available for the motors:
• integrated holding brake
• drive shaft with key
• absolute encoder for detecting the current position of the load without
travelling to reference point
Typical applications of Rexroth EcoDrive Cs are:
• handling systems
• packaging machines
• mounting systems
• printing machines
• machine tools
Introduction to the System
1-1
