10-4
Additional Components

Encoder Extension Cable IKS0232

3000
3010
3040
INS0753/C01
strip
4 mm
Shield
VCC
GND
VB
GND
SD
/SD
Secure solder joint (strand - shield) with shrink hose (3070 = 12 mm)!
order length = length of unfinished cable
100
2990
IKS0232
3060
remove
sheath
35 mm
3050
9
white
1
brown
2
black
3
red
4
grey
5
pink
6
Fig. 10-4:
Encoder extension cable IKS0232
100
2990
0500
IKS0232
INK0750
3060
remove
sheath
35 mm
3050
0,5 mm²
0,5 mm²
0,25 mm²
0,25 mm²
0,25 mm²
0,25 mm²
DOK-ECODR3-DKC**.3-CS*-PR02-EN-P
Rexroth EcoDrive Cs Drives
3020
3040
3030
INS0758/C01
strip
4 mm
9
Shield
1
VCC
2
GND
3
VB
4
GND
5
SD
6
/SD
