5-20
Electrical Connections
Line for Voltage Connection of
Controlling the Motor Holding
line cross section
Brake
voltage stability of a single strand against
ground:
line routing:
max. inductance between 24 V source
and X5_3:
The drive controller assumes the control of the holding brake.
Brake
Rexroth EcoDrive Cs Drives
2
min. 1 mm
≥ 750 V
parallel where possible (twist)
100 µH
(corresponds to approx. 2 x 75 m)
