5.2
Connections Dependent on the Device
DKC01.3 – Analog/Parallel Interface
DOK-ECODR3-DKC**.3-CS*-PR02-EN-P
View of Interface to Master Communication
schnittstellen_X7_X54.fh7
X5_4: Analog and digital I/Os
X7:
Incremental and absolute encoder emulation
Fig. 5-45: View of interface to master communication
Electrical Connections
X7
X5_4
ana_para_front.FH7
5-23
