REXROTH EcoDrive Cs Project Planning Manual page 58

5-10
Electrical Connections
Motor Cables
For connecting drive controller and motor please use the appropriate
Rexroth motor power cables. See chapter 10.1
Cable length:
The maximum cable length is 40 m with:
•
ready-made Rexroth cable
• ambient temperature of ≤ 40 °C according to EN 60204
•
maximum switching frequency of 8 kHz
No warranty!
If cables manufactured by a company other than Bosch
Rexroth resp. cables longer than 40 m are used, the
Bosch Rexroth warranty for the entire drive system
WARNING
becomes invalid.
Use ready-made Rexroth cables!
Rexroth EcoDrive Cs Drives
DOK-ECODR3-DKC**.3-CS*-PR02-EN-P
