Additional Components
Rexroth EcoDrive Cs Drives
Mounting
• If present, unscrew screw of ground connection:
1
geberadapter_erdungsschraube.fh7
1:
Screw of ground connection
Fig. 10-15: Screw of ground connection
• Screw angle plate to the bottom of drive controller:
geberadapter_winkel.fh7
Fig. 10-16: Angle plate
DOK-ECODR3-DKC**.3-CS*-PR02-EN-P
