Identifying the Server Ports

These sections describe the pinouts of the server connectors.
Description
Review the Gigabit Ethernet ports.
Review the network management ports.
Review the serial management ports.
Review the video connectors.
Review the USB ports.
Related Information
"About the Oracle Exadata Storage Server X5-2 High Capacity" on page 13
■

Gigabit Ethernet Ports

The server has four auto-negotiating 100/1000/10GBASE-T Gigabit Ethernet (GbE) system
domain ports. All four Ethernet ports use a standard RJ-45 connector. The transfer rates are
shown in the following table.
TABLE 8
Connection Type
Fast Ethernet
Gigabit Ethernet
10 Gigabit Ethernet
The following figure and table describe the 10-GbE port pin signals.
Ethernet Port Transfer Rates
IEEE Terminology
100BASE-T
1000BASE-T
10GBASE-T
Links
"Gigabit Ethernet Ports" on page 169
"Network Management Port" on page 170
"Serial Management Port" on page 171
"Video Connector" on page 173
"USB Ports" on page 174
Transfer Rate
100 Mbps
1,000 Mbps
10,000 Mbps
Identifying the Server Ports 169
