9.4 At-a-glance Guide to Adjustment Functions

Press one of the keys shown below at power-on to select the corresponding mode.

Key operations

Set DIP switch 2 to the ON position and press one of the keys shown below at power-on to select the
corresponding adjustment mode.
MODE \ KEY
Offset initialization(*1)
Shading correction
*1: Offset initialization resets all settings stored in NVRAM to their default values.
(Feed correction, origin, X overlaps, Y offsets, and density values will be reset to their defaults.)
CS2000-UM-251-9370
FORWARD REVERSE
-
Press
9-7
9. BOARDS AND ELECTRICAL COMPONENTS
STOP
- Press
- -
