Step 2
(1) Insert the ends of basket mounting bar 1 into the two basket mounting bar guides.
(2) With the bar ends fully inserted, insert the two decorative screws at the innermost end of the long screw
hole on the basket mounting bar guides and tighten until the screws are fully inserted into the holes at
both ends of basket mounting bar 1.
Decorative screws
If you are using the document support wires on the CS2000, pull out basket mounting bar 1 as required.
To prevent damage to the basket or to the scanner itself, do not place any heavy objects in the basket or on the bas-
ket mounting bars. Do not allow documents to pile up in the basket, as they may become damaged.
CS2000-UM-251-9370 13-2
Decorative screws
13. OPTION
