4.

OPERATION AND CONNECTION

4.1 Connecting the Scanner to a Computer

Before you can start connecting the scanner to the computer, you need to prepare (confirm) the computer
system's environment.
(1) Confirm that the computer's operating system has been properly installed.
(2) Confirm that a SCSI adapter has been connected to the computer.
(3) Confirm that the SCSI driver has been installed in the computer.
Connecting the CS2000 to a Computer for the First Time
For Windows 95 or Windows 95 Version a:
(1) After checking that the scanner and the computer are properly connected via the SCSI interface cable,
turn on the scanner first and then turn on the computer.
(2) When Windows 95 has been booted, the window below appears.
(3) Select "Do not install a driver," then click the "OK" button.
(4) The Windows 95 Desktop appears and the CS2000 is acknowledged by the computer.
For Windows 95 Version B:
(the actual screen displayed may be different from the one shown, depending on which version of Windows
95 you have)
(1) After checking that the scanner and the computer are properly connected via the SCSI interface cable,
turn on the scanner first and then turn on the computer.
(2) When Windows 95 has been booted, the window below appears.
CS2000-UM-251-9370 4-1
4. OPERATION AND CONNECTION
