8.18 Cover Open Sensor

Disassembly procedure
8.2
p.8-2
Detaching the document
hold-down unit
Detaching the cover open sensor
(1) Remove the two black M2L8 binding head screws from the rear surface of the front separator plate.
(2) Detach the main board connectors from the cables.
(3) Disconnect the cables and detach the cover open sensor.
Reattaching the cover open sensor
(1) Reattach the cover open sensor by reversing the sequence of steps in which it was detached.
For optimal sensitivity, attach the sensor as far up as possible.
CS2000-UM-251-9370
8. DISASSEMBLING AND ADJUSTING MECHANICAL PARTS
8.4
p.8-5
Detaching the side cover
(the right-hand side cover only)
Cover
Co v er
open sensor
open sensor
Rear surface of the
Rear surf ace of the
front separator plate
front separ ator plate
Main board
8-22
8.8
p.8-9
Detaching the large and small bottom
plates (the small right-hand plate only)
M2L8
M2L8
binding head
binding head
screws
scre ws
Cover open sensor
Co v er open sensor
connector (red cable)
connector (red cab le)
8.13
p.8-15
Detaching the separator plates
(the front plate only)
This Section
Detaching the cover open
sensor
