6.

RECOMMENDED PARTS LIST

No Parts No
1 378019021 Drive Belt
2 500050305 ID Switch
3 500050731 Memory 128MB
4 500050736 24V Switching Power Supply
5 500050745 Motor
6 694450002 Cable CIS to main board L
7 694450033 Cable CIS to main board S
8 500050803 3.3V Switching Power Supply LDA15F-3-3.3
9 500050804 5V Switching Power Supply
10 694450051 Cooling Fan
11 502112009 Power Switch
12 502210002 Paper Sensor
13 640310450 Document Support Wires
14 641000663 CS Retaining Plate
15 641000240 Drive Roller
16 641200100 Front Guide 20
17 641200120 Left Side Cover L20
18 641200130 Right Side Cover R20
19 641200290 Top Cover
20 641000840 Control Panel
21 694440011 Rear Sensor Cable
22 694440021 Front Sensor Cable
23 694440032 Sensor Unit
24 774014500 Main Board
25 774014501 CIS Control Board A
26 774014502 CIS Control Board B
27 774014503 CIS Control Board C
28 774014900 (Maintenance)
29 774012810 (Maintenance)
30 774012820 (Maintenance)
31 794021091 Control Panel Board
32 641200200 Shading Assy-RMD
33 774014901 (Maintenance)
CS2000-UM-251-9370
Description
Belt 60S2M380
ID Switch
D2V4A8D-CL2
LDA75F-24-H
KT60LM06-551
CS2000C-1
CS2000C-4
LDA15F-5
CS2000C-6
Sw,AJ7201B
PS-R50L-A
IS31 Document Support Wires
CS Retaining Plate
CS Drive Roller
CS20 Front Guide
CS Side Cover Left 20
CS Side Cover Right 20
CS Top Cover 20
CS10 Control Panel
CS1000C-1
CS1000C-2
CS1000C-3
Main Board
CIS Control Board A
CIS Control Board B
CIS Control Board C
Image Sensor Unit
Pinch Roller Unit
Glass Base Unit
IS21 Control Panel Board
Calibration Sheet, Color Correction Sheet
Document Hold Down Unit CS2000
6-1
6. RECOMMENDED PARTS LIST
Part name Q'ty Remarks
1 Same as CS1000
1 Same as CS1000
1 Same as CS1000
1 Same as CS1000
1 Same as CS1000
1 Same as CS1000
1 Same as CS1000
1 Same as CS1000
1 Same as CS1000
1
1 Same as CS1000
1 Same as CS1000
3 Same as CS1000
1
2 Same as CS1000
1
1
1
1
1 Same as CS1000
1 Same as CS1000
1 Same as CS1000
1 Same as CS1000
1
1
1
1
1
2 Same as CS1000
1 Same as CS1000
1 Same as CS1000
1
1
