NewTek TriCaster Mini User Manual page 84

FIGURE 52
Let's assign sources to a couple of the DSKs (Downstream Keyers) now (we'll be using
these shortly):
1. Add a title to the GFX 1 (or simply GFX, for TriCasters with just one Graphics
player) playlist as follows:
a. Click the Graphics tab, then click the large + (Add Media) button at left
in the footer of the GFX 1 player to open a custom Media Browser
(Figure 52).
b. Click the NewTek location at left (under the Titles heading) in the
Media Browser.
c. In the file pane at right, scroll down to locate a title that does not cover
the entire screen (such as the one shown in Figure 52).
2. In the same manner, add a different second title to the playlist.
3. Right-click the playlist icon for this second title, and select Send to Buffer 1
from the icon menu.
Page | 68
DSK S
OURCES
