b. Component – Attach your device to the second, third and fourth BNC
connectors (Y, Pb and Pr).
c. Y/C
If your S-Video equipment and cabling has the usual 4-pin mini-DIN
connectors, you will need an 'S-Video to dual BNC' adapter.
i. Attach the Y (luma) connector of your device to the second analog
ii. Attach the C (chroma) connector to the third analog connector
d. Composite – Attach the device's connector to the first (top) analog
connector (just above the pair labeled Y/C).
2. Connect TriCaster's audio outputs:
a. Analog audio – Connect external audio devices to the connectors in the
AUDIO OUT section.
8-input TriCasters offer two pairs of four audio output connectors:
i. Connectors 1a-(1b or 1d) provide sound from the mix assigned to
Output 1 (defaults to Master in Output Configuration)
ii. Connectors 2a-(2b or 2d) provide sound from the mix assigned to
Output 2 (defaults to Aux in Output Configuration)
Note: These two output groups are actually treated by TriCaster as four
independent stereo outputs, each configured and controlled separately;
see Chapter 15, Audio.
b. Digital audio – A separate digital audio connection is not necessary for SDI
or HDMI output with embedded audio. AES/EBU connectors are provided
for Output 1(channels a-d) on 8-input models.
Hint: TriCaster's SDI and analog output sections can be used simultaneously.
example, you could use the Composite output to view your program on a local composite
monitor at the same time as you use the SDI connection to supply broadcast equipment.
BNC connector row (labeled Pb at far left in the VIDEO IN group).
(labeled Pr).
For
Page | 33
