POS/SCALE

Move the joystick horizontally, vertically or diagonally (as viewed from
above) to move delegated video source(s) on its X and Y axes.

Twist the joystick clockwise to scale delegated source(s) up, or counter-
clockwise to scale down.
Hint: When multi-delegate selections are active for the Positioner, adjustments are
generally relative to the current state for individual delegates, as opposed to absolute.
ROT (R )
OTATE
When the POSITIONER DELEGATE selection is anything other than VIRTUAL ZOOM
or SHUTTLE:

Move the joystick horizontally (as viewed from above) to rotate delegated
sources on the Y axis.

Move the joystick vertically to rotate delegated sources on the X axis.

Twist the joystick clockwise/counter-clockwise to rotate delegated sources
on the Z axis.
CROP
Except when the POSITIONER DELEGATE selection is VIRTUAL ZOOM or SHUTTLE:

Twist the joystick clockwise (as viewed from above) to crop delegated sources
inward on all 4 edges, maintaining the original aspect ratio.

Twist the joystick counter-clockwise to reduce cropping of delegated sources
on all 4 edges.

Move the joystick horizontally to crop only the left edge of delegated sources.

Move the joystick horizontally with the joystick button pressed to crop only
the right edge of delegated sources.

Move the joystick vertically to crop only the top edge of delegated sources.

Move the joystick vertically with the joystick button pressed to crop only the
bottom edge of delegated sources.
