5. Copy the file, and paste the copy in at the same location.
6. Double-click the new profile to open it in the Windows Media Profile Editor.
7. Make such changes to the settings as you see fit, then click the Save and Close
button.
8. Rename the modified profile to differentiate it from the others in the same
folder.
9. Close the folder, and re-launch TriCaster.
C
REATING A
1. From TriCaster's Startup Screen, click the Shutdown icon, and select
Administration Mode.
2. Press the Windows® key on your keyboard, and launch Adobe Flash Media
Live Encoder® from the Windows® Start Menu.
3. Select Open Profile from the File menu in the encoder application.
4. Navigate to C:\TriCaster\Configuration\Streaming Profiles\FlashProfiles\.
5. Continue to identify a profile (.xml file) similar to the one you wish to create
inside the appropriate sub-folder at that location, and click the Open button in
the file explorer.
6. In Adobe Flash Media Live Encoder®, modify the settings for the profile to suit
your need.
7. Select Save Profile from the File menu.
C
RTMP S
USTOM
TREAMING
P
ROFILE
Page | 461
